Fire Resistance of Precast Concrete Sandwich Cladding Panels with FRP Connectors
-
摘要: 为了研究无机保温砂浆层对配纤维增强复合材料（FRP）连接件预制混凝土夹心保温墙板抗火性能的影响，通过考虑高温对混凝土、钢筋、FRP材料的影响，在有限元分析软件ABAQUS中建立温度-位移场耦合分析模型，开展标准火灾有限元分析，并与2片配FRP连接件的预制混凝土夹心保温墙板耐火试验结果进行对比，验证了模型的有效性，并进一步开展参数分析，研究了有无平面外荷载和受火时间对墙板抗火性能的影响。研究表明：保温砂浆层可提升预制混凝土夹心保温外挂墙板（PSCP）的热阻能力、抗弯刚度，降低墙板内部的热对流；FRP连接件在受火60 min内轻微损伤，达到玻璃化温度后仍能提供抗剪刚度，所以玻璃化温度对于判断墙板发生连接件破坏是偏保守的温度；增加平面外荷载使墙板挠度变大，但对温度场无明显影响；受火180 min可能将导致FRP连接件丧失与混凝土板的黏结锚固能力。
-
关键词:
- 预制混凝土夹心保温外挂墙板 /
- 无机保温砂浆 /
- FRP连接件 /
- 温度-位移场耦合有限元分析 /
- 标准火灾
Abstract: To investigate the influence of the inorganic insulation mortar layer on the fire resistance of precast concrete sandwich panels（PCSPs） with fiber-reinforced polymer （FRP） connectors， a coupled temperature-displacement finite element model was developed using the finite element software ABAQUS by considering the effects of high temperature on concrete， rebars， and FRP materials. Finite element analyses were conducted under standard fire conditions， and the results were validated against fire resistance tests on two PCSPs with FRP connectors. Subsequently， parametric analyses were performed to examine the effects of out-of-plane loading and fire exposure duration. The results showed that the inorganic mortar increased thermal resistance and flexural stiffness but reduced heat convection within the panel. The FRP connectors were slightly damaged while still capable of providing shear capacity， and the glass transition temperature was found to be a conservative indicator of their failure. Although out-of-plane loading led to larger panel deflections， it had no appreciable effect on the temperature distribution. Compared to the 60-minute fire exposure， the FRP connectors were more prone to anchorage failure after 180 minutes of fire exposure. -
[1] LI Y，XUE W，YUN Y，et al. Reversed cyclic loading tests on precast concrete sandwich shear walls under different axial compression ratios［J］. Journal of Building Engineering，2022，54：104619. [2] 朱筱俊，李向民，杨建，等. 预制复合保温墙体抗火性能试验研究［J］. 东南大学学报（自然科学版），2017，47（6）：1208-1215. [3] HULIN T，HODICKY K，SCHMIDT J W，et al. Experimental investigations of sandwich panels using high performance concrete thin plates exposed to fire［J］. Materials and Structures，2016，49（9）：3879-3891. [4] CHEN J，HAMED E，GILBERT R I. Structural performance of concrete sandwich panels under fire［J］. Fire Safety Journal，2021，121：1-15. [5] HUANG J Q，XU Y Y，HUANG H，et al. Structural behavior of FRP connector enabled precast geopolymer concrete sandwich panels subjected to one-side fire exposure［J］. Fire Safety Journal，2022，128：103524. [6] European Committee for Standardization. Design of concrete structures-part 1-2：general rules-structural fire design：EN 1992-1-2［S］. Brussel：European Committee for Standardization，2004. [7] ASLANI F，BASTAMI M. Constitutive relationships for normal-and high-strength concrete at elevated temperatures［J］. ACI Materials Journal，2011，108（4）：355-364. [8] 李国强，韩林海，楼国彪，等． 钢结构及钢-混凝土组合结构抗火设计［M］． 北京：中国建筑工业出版社，2006． [9] European Committee for Standardization. Design of steel structures-part 1.2：general rules-structural fire design：Eurocode 3［S］. Brussels：European Committee for Standardization，1993. [10] 日本建筑省． 建筑物综合防火设计［M］．孙金香，高温，译. 天津：天津翻译出版公司，1988. [11] KELLER T，TRACY C，ZHOU A. Structural response of liquid-cooled GFRP slabs subjected to fire-part I：material and post-fire modeling［J］. Composites Part A：Applied Science and Manufacturing，2006，37（9）：1286-1295. [12] 王晓璐，查晓雄． 高温下GFRP筋力学性能的试验研究［J］． 华南理工大学学报（自然科学版），2011，39（9）：75-81. [13] ZAIDI A，MASMOUDI R. Thermal effect on fiber reinforced polymer reinforced concrete slabs［J］. Canadian Journal of Civil Engineering，2008，35（3）：312-320. [14] International Organization for Standardization. Fire resistance tests-elements of building construction-part 1：ISO 834-1［S］. Geneva：International，Organization for Standardization，1999. [15] 中华人民共和国住房和城乡建设部. 建筑设计防火规范：GB 50016—2014［S］. 北京：中国计划出版社，2014. [16] 中国国家标准化管理委员会. 建筑构件耐火试验方法 第1部分 通用要求：GB/T 9978.1—2008［S］. 北京：中国计划出版社，2009. [17] 李志杰. 灾害荷载下预制混凝土墙体试验研究［D］. 上海：同济大学，2014. -
