Seismic Performance of UHPC Post-Cast Precast Concrete Cruciform Beam-Column Joints
-
摘要: 提出一种适用于超高性能混凝土(UHPC)后浇节点的上下柱纵筋错位连接构造,有望提高装配过程中的容错性。通过4个足尺试件的低周反复加载试验与有限元模拟,评估了各节点的滞回性能、刚度退化与耗能能力。通过参数化分析在保持其余参数一致的前提下隔离关键变量影响,从而弥补了试验中多变量同时变化的局限性,提升了对单一因素影响针对性评估的能力。结果表明:新构造节点的峰值承载力仍能保持与RC-A-2相近水平,累计耗能能力与延性略有提升。破坏模式均为梁端弯曲破坏,符合“强节点、弱构件”原则;大直径纵筋方案在保持承载力基本不变的同时,显著降低了节点区钢筋数量,增加了钢筋的间距,减少了装配过程中钢筋碰撞的风险,有望提升装配效率;有限元分析结果与试验结果吻合较好,验证了模型合理性;相较于传统材料后浇的装配式节点,UHPC后浇装配式节点展现出较优的抗震性能和抗剪切变形能力。
-
关键词:
- UHPC后浇装配节点 /
- 抗震性能 /
- 低周反复荷载 /
- 滞回性能 /
- 有限元模拟
Abstract: This paper proposes a staggered longitudinal reinforcement configuration suitable for UHPC post-cast precast joints, which significantly improves assembly tolerance during construction. The hysteretic performance, stiffness degradation, and energy dissipation capacity of the joints were evaluated through quasi-static loading tests and finite element simulations on four full-scale specimens. Parametric studies isolated key variables, overcoming the limitation of concurrent changes in tests and allowing targeted evaluation. The results indicated that the proposed joint configuration maintained a peak bearing capacity comparable to that of the specimen RC-A-2, with slight improvements in cumulative energy dissipation and ductility. All specimens exhibited a flexural failure mode at the beam ends, in accordance with the “strong joint-weak component” principle. Furthermore, tests demonstrated that the larger-diameter longitudinal rebar scheme substantially reduced the number of rebars and increased rebar spacing in the joint zone while maintaining essentially equivalent bearing capacity. This effectively reduced the risk of rebar collision during assembly, thereby showing potential for improving construction efficiency. The numerical analysis results showed good agreement with the experimental data, validating the model. This confirmed that the UHPC post-cast precast joint exhibits superior seismic performance and shear resistance compared to joints with conventional cast-in-place materials. -
[1] 中华人民共和国住房和城乡建设部. 装配式混凝土结构技术规程:JGJ 1—2014[S]. 北京:中国建筑工业出版社,2014. [2] YAN Q,CHEN T,XIE Z. Seismic experimental study on a precast concrete beam-column connection with grout sleeves[J]. Engineering Structures,2018,155:330-344. [3] 黄俊,康爽,单英杰,等. UHPC后浇装配式节点抗震性能试验研究[J]. 铁道科学与工程学报,2024,21(1):286-298. [4] 吕雪源,王英,符程俊,等. 活性粉末混凝土基本力学性能指标取值[J]. 哈尔滨工业大学学报,2014,46(10):1-9. [5] CHEOK G S,LEW H S. Performance of precast concrete beam-to-column connections subject to cyclic loading[J]. PCI Journal,1991,36(3):56-67. [6] 曾宪纯,马旭新,李海波,等. 连接预制梁钢筋的直型半灌浆套筒组件研制及标准化应用[J]. 建筑结构,2019,49(增刊1):904-910. [7] 陈柯臻,李秀领,李言,等. 自密实GHPFRCC装配式梁柱节点抗震性能研究[J]. 施工技术(中英文),2022,51(15):39-45. [8] 丁然,芶双科,樊健生,等. 后浇LSECC装配整体式梁受力性能试验研究[J]. 工程力学,2018,35(10):56-65. [9] 管东芝,田文华,陈子轩,等. 基于UHPC壳的装配式混凝土梁柱连接抗震性能研究[J]. 土木工程学报,2023,56(1):49-56. [10] MAYA L F,ZANUY C,ALBAJAR L,et al. Experimental assessment of connections for precast concrete frames using ultra high performance fibre reinforced concrete[J]. Construction and Building Materials,2013,48:173-186. [11] 郑七振,陈威钢,龙莉波,等. UHPC连接的节点预制-构件预制装配式框架抗震性能试验研究[J]. 上海理工大学学报,2019,41(6):584-590. [12] 冯军骁,郑七振,龙莉波,等. 超高性能混凝土连接的预制梁受弯性能试验研究[J]. 工业建筑,2017,47(8):59-65. [13] 马福栋,邓明科,杨勇. 超高性能混凝土装配整体式框架梁柱节点抗震性能研究[J]. 工程力学,2021,38(10):90-102. [14] 中国建筑科学研究院. 建筑抗震试验方法规程:JGJ/T 101—2015[S]. 北京:中国建筑工业出版社,2015. [15] PARK R. Evaluation of ductility of structures and structural assemblages from laboratory testing[J]. Bulletin of the New Zealand Society for Earthquake Engineering,1989,22(3):155-166. [16] 中华人民共和国住房和城乡建设部. 混凝土结构设计标准:GB/T 50010—2011[S]. 北京:中国建筑工业出版社,2024. [17] 马亚峰. 活性粉末混凝土(RPC200)单轴受压本构关系研究[D]. 北京:北京交通大学,2006. [18] 徐海宾,邓宗才. 新型UHPC应力-应变关系研究[J]. 混凝土,2015(6):66-68. [19] 方自虎,简旭阳,周尧,等. 考虑屈曲的钢筋滞回模型[J]. 武汉大学学报(工学版),2016,49(2):254-258. [20] 周剑. 预制混凝土空心模剪力墙应用技术研究[D]. 北京:清华大学,2015. -
