铬污染土的还原效应与微生物矿化机制研究

严邦全; 魏明俐; 威巍; 申水玥; 宋亚儒

doi:10.3724/j.gyjzG25080103

铬污染土的还原效应与微生物矿化机制研究

doi: 10.3724/j.gyjzG25080103

严邦全¹,
魏明俐^2,3,
威巍^2, ,,
申水玥⁴,
宋亚儒⁴

1. 江苏省地质工程勘察院, 南京 211102;
2. 中国科学院武汉岩土力学研究所, 岩土力学与工程国家重点实验室, 武汉 430071;
3. 江苏中宜生态土研究院有限公司, 江苏宜兴 214200;
4. 青岛理工大学土木工程学院, 山东青岛 266520

基金项目:

江苏省自然科学基金项目（BK2023022776）。

详细信息

作者简介:
严邦全，高级工程师，主要从事岩土工程方面的研究工作，ybqgood@163.com。

通讯作者:
威巍，博士，主要从事污染泥土渣资源化利用方面的研究工作，weiwei204@mails.ucas.ac.cn。

计量
- 文章访问数: 23
- HTML全文浏览量: 7
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2025-08-01
- 网络出版日期: 2026-08-31
- 刊出日期: 2026-07-20

Research on the Reduction Effect and Microbial Mineralization Mechanism of Cr-Contaminated Soil

1. Geo-engineering Investigation Institute of Jiangsu Province, Nanjing 211102, China;
2. State Key Laboratory of Geomechanics and Geotechnical Engineering, Institute of Rock and Soil Mechanics, Chinese Academy of Sciences, Wuhan 430071, China;
3. Jiangsu Institute of Zoneco Co., Ltd., Yixing 214200, China;
4. School of Civil Engineering, Qingdao University of Technology, Qingdao 266520, China

摘要

摘要: 系统研究了化学还原结合微生物矿化修复Cr（Ⅵ）污染土的效果。通过改变胶结液的浓度和养护龄期，利用无侧限抗压强度测试和毒性浸出试验评价处理前后污染土样的修复效果，结合微观结构测试，从微观尺度上揭示微生物矿化修复Cr（Ⅵ）污染土的作用机理，为Cr（Ⅵ）污染土修复提供新的理论依据和参考。结果表明：化学还原结合微生物矿化技术能够有效地修复Cr（Ⅵ）污染土，固化土的无侧限抗压强度可达到0.227 MPa，降低固化土的Cr（Ⅵ）浸出浓度，Cr（Ⅵ）去除率达到96%以上；通过化学-微生物协同还原矿化技术对污染土体进行修复处理，处理后的土样pH先下降后上升，电导率呈显著上升的趋势，而尿素水解反应是引发上述参数升高的关键驱动因素；在经化学还原协同微生物矿化处理的Cr（Ⅵ）污染土中，检测到CaCO₃晶体的形成产物，X射线衍射与能谱分析证实，Cr（Ⅵ）与Cr（Ⅲ）污染物以表面吸附或晶格固溶形式存在于CaCO₃矿物相中，其中Cr（Ⅲ）主要通过同晶置换方式进入方解石晶体结构，通过共沉淀反应生成了化学组成稳定的复合物［Ca₁₀Cr₆O₂₄（CO₃）］，该物质表现出较低的离子迁移特性及生物可利用特征。
- 化学-生物联合修复 /
- 微生物矿化 /
- Cr（Ⅵ）污染土 /
- 胶结液浓度 /
- 土壤固化
Abstract: This study systematically investigated the effectiveness of chemical reduction combined with microbial mineralization in remediating Cr（Ⅵ）-contaminated soil. The remediation performance was evaluated under varying cementation solution concentrations and curing ages using unconfined compressive strength tests and toxicity leaching experiments. Microstructural analysis was employed to elucidate the remediation mechanisms at the microscale， providing new theoretical foundations for the remediation of Cr（Ⅵ）-contaminated soil. The results demonstrated that the integrated chemical-microbial reduction-mineralization technology effectively remediated Cr（Ⅵ）-contaminated soil， achieving a compressive strength of 0.227 MPa in the solidified soil and reducing the Cr（Ⅵ） leaching concentration， with a removal efficiency exceeding 96%. Post-treatment analysis revealed that soil pH presented an initial decrease followed by a rise， and electrical conductivity exhibited a marked upward trend， which were primarily driven by urea hydrolysis reactions. Carbonate crystal formation was observed in treated samples， and X-ray diffraction and energy-dispersive spectroscopy （EDS） confirmed that hexavalent and trivalent chromium contaminants were immobilized through surface adsorption or lattice solid-solution mechanisms. Notably， Cr（Ⅲ） predominantly entered the calcite crystal structure through isomorphous substitution， forming stable calcium-chromium coprecipitates （Ca₁₀Cr₆O₂₄（CO₃）） characterized by low mobility and bioavailability.
- chemical-biological remediation /
- microbial mineralization /
- Cr（Ⅵ）-contaminated soil /
- cementation solution concentration /
- soil solidification

HTML全文

参考文献(32)

[1]	王兴润，李磊，颜湘华，等.铬污染场地修复技术进展[J].环境工程，2020，38（6）:1-8.
[2]	ASHRAF A，BIBI I，NIAZI N K，et al. Chromium（VI）sorption efficiency of acid-activated banana peel over organo-montmorillonite in aqueous solutions[J]. International Journal of Phytoremediation，2017，19（7）:605-613.
[3]	杨文晓，张丽，毕学，等.六价铬污染场地土壤稳定化修复材料研究进展[J].环境工程，2020，38（6）:16-23.
[4]	谷庆宝，马福俊，张倩，等.污染场地固化/稳定化修复的评价方法与标准[J].环境科学研究，2017，30（5）:755-764.
[5]	XIE P，LIU Z，LI J，et al. Pollution and health-risk assessments of Cr-contaminated soils from a tannery waste lagoon，Hebei，north China:with emphasis on Cr speciation[J]. Chemosphere，2023，317:137908.
[6]	姚瑶，张世熔，王怡君，等. 3种环保型淋洗剂对重金属污染土壤的淋洗效果[J].环境工程学报，2018，12（7 ）:2039-2046.
[7]	XU Y，LIU C，QU Y，et al. Modified pineapple peel extract coupled with electrokinetic techniques for remediation of chromium-contaminated soil[J]. Process Safety and Environmental Protection，2022，160:424-433.
[8]	ZHAO X，TANG D，JIANG Y. Effect of the reduction–mineralization synergistic mechanism of Bacillus on the remediation of hexavalent chromium[J]. Science of the Total Environment，2021，777:146190.
[9]	ZHANG T，WANG T，WANG W，et al. Reduction and stabilization of Cr（Ⅵ）in soil by using calcium polysulfide:Catalysis of natural iron oxides[J]. Environmental Research，2020，190:109992.
[10]	YANG Z，ZHANG X，JIANG Z，et al. Reductive materials for remediation of hexavalent chromium contaminated soil-a review[J]. Science of the Total Environment，2021，773:145654.
[11]	HUANG X，MIN D，LIU D，et al. Formation mechanism of organo-chromium（III）complexes from bioreduction of chromium（VI）by Aeromonas hydrophila[J]. Environment international，2019，129:86-94.
[12]	刘汉龙，赵常，肖杨.微生物矿化反应原理、沉积与破坏机制及理论:研究进展与挑战[J].岩土工程学报，2024，46（7）:1347-1358.
[13]	LI D，TIAN K，ZHANG H，et al. Experimental investigation of solidifying desert aeolian sand using microbially induced calcite precipitation[J]. Construction and Building Materials，2018，172:251-262.
[14]	SONG Z，FANG L，WANG J，et al. Use of biogas solid residue from anaerobic digestion as an effective amendment to remediate Cr（Ⅵ）-contaminated soils[J]. Environmental Science and Pollution Research，2019，26:13041-13053.
[15]	FU L，FENG A，XIAO J，et al. Remediation of soil contaminated with high levels of hexavalent chromium by combined chemical-microbial reduction and stabilization[J]. Journal of Hazardous Materials，2021，403:123847.
[16]	中华人民共和国住房和城乡建设部.土工试验方法标准:GB/T 50123—2019[S].北京:中国计划出版社，2019.
[17]	喻成成，卢正，姚海林，等.微生物诱导碳酸钙沉淀改性膨胀土试验研究[J].岩土力学，2022，43（增刊1）:157-163.
[18]	JIANG N J，LIU R，DU Y J，et al. Microbial induced carbonate precipitation for immobilizing Pb contaminants:toxic effects on bacterial activity and immobilization efficiency[J]. Science of the Total Environment，2019，672（1）:722-731.
[19]	生态环境部.土壤环境质量建设用地土壤污染风险管控标准（试行）:GB 36600—2018[S].北京:中国环境科学出版社，2018.
[20]	生态环境部.土壤电导率的测定电极法:HJ 802—2016[S].北京:中国环境科学出版社，2016.
[21]	CHOI S，PARK S，WU S，et al. Methods for calcium carbonate content measurement of biocemented soils[J]. Journal of Materials in Civil Engineering，2017，29（11）:06017015.
[22]	US EPA. Method 1311:Toxicity characteristic leaching procedure[Z]. Washington D C:U.S.Environmental Protection Agency，1992.
[23]	生态环境部.土壤氧化还原电位的测定电位法:HJ 746—2015[S].北京:中国环境科学出版社，2015.
[24]	DENG X J，YUAN Z X，LI Y，et al. Experimental study on the mechanical properties of microbial mixed backfill[J]. Construction and Building Materials，2020，265:120643.
[25]	生态环境部.危险废物鉴别标准浸出毒性鉴别:GB 5085.3—2007[S].北京:中国环境科学出版社，2007.
[26]	崔明娟，郑俊杰，章荣军，等.化学处理方式对微生物固化砂土强度影响研究[J].岩土力学，2015，36（增刊1）:392-396.
[27]	ZHAO X，DING T，YI J. Effect of the reduction–mineralization synergistic mechanism of Bacillus on the remediation of hexavalent chromium[J]. Science of the Total Environment，2021，777:146190.
[28]	QIAN X，FANG C，HUANG M，et al. Characterization of fungal-mediated carbonate precipitation in the biomineralization of chromate and lead from an aqueous solution and soil[J]. Journal of Cleaner Production，2017，164:198-208.
[29]	YONG Z，CHEN Z，DU Y，et al. Microbiologically induced calcite precipitation technology for mineralizing lead and cadmium in landfill leachate[J]. Journal of Environmental Management，2021，296:113199.
[30]	LI F，ZHENG Y，TIAN J，et al. Cupriavidus sp. strain Cd02-mediated pH increase favoring bioprecipitation of Cd²⁺ in medium and reduction of cadmium bioavailability in paddy soil[J]. Ecotoxicology and Environmental Safety，2019，184:109655.
[31]	LIU M，CAI L，LUO H. Effect of nano-silica on microbiologically induced calcium carbonate precipitation[J]. Construction and Building Materials，2022，314:125661.
[32]	WANG T，LIU Y，WANG J，et al. In-situ remediation of hexavalent chromium contaminated groundwater and saturated soil using stabilized iron sulfide nanoparticles[J]. Journal of Environmental Management，2019，231:679-686.
