Experimental Research on the Flexural Performance of FRP-Reinforced Composite Concrete Slabs Without Protruding Rebars
-
摘要: 为解决板边不出筋混凝土叠合板承载能力降低、变形大的问题,提出在预制底板边设置凹槽和在板底跨缝处粘贴纤维复材的增强方式。通过1块整浇板和8块板边不出筋混凝土叠合楼板的静载试验,对试件的受弯特征、破坏形态、承载特性和变形能力进行了对比分析。结果表明:密拼叠合板试件的承载力、刚度和延性均明显小于整浇板;上述增强方式可以在一定程度上增强叠合板底部的应力传递和整体性,提高叠合板的受力性能;拼缝位置叠合面设置附加钢筋的配筋率和锚固长度对叠合板的受力性能有明显影响;增加凹槽深度的试件表现出相对突出的承载能力和变形性能,且延性相对较大;加载过程中纤维复材对板底的约束作用提高了叠合板的开裂荷载,增强了板底拼缝两侧的应力传递,减小了板缝“变形集中”的程度,提高了叠合板的刚度和延性。Abstract: In order to solve the problems of reduced bearing capacity and large deformation of concrete composite slabs without protruding rebars, reinforcement methods such as setting grooves at the edges of the prefabricated bottom slabs and pasting fiber-reinforced composites at the cross-seam positions of the slab bottom are proposed. Through the static load tests of one monolithic cast slab and eight concrete composite floor slabs without protruding rebars, a comparative analysis was carried out on the flexural characteristics, failure modes, bearing characteristics, and deformation capacities of the specimens.The results showed that the bearing capacity, stiffness, and ductility of the closely spliced composite slab specimens were significantly smaller than those of the monolithic cast slab. Through the strengthening measures such as grooving at the edge of the slab and pasting fiber composites across the cracks at the bottom of the slab, the stress transfer and integrity at the bottom of the composite slab were enhanced to a certain extent, and the mechanical properties of the composite slab were improved. The reinforcement ratio and anchorage length of the additional rebars set at the composite surface of the splicing joint had a significant impact on the mechanical properties of the composite slab. The specimens with increased groove depth exhibited relatively outstanding bearing capacity and deformation performance, with good ductility. During the loading process, the restraining effect of the fiber composite materials on the bottom of the slab increased the cracking load of the composite slab, enhanced the stress transfer on both sides of the splicing joint at the bottom of the slab, reduced the degree of "deformation concentration" at the slab joint, and improved the stiffness and ductility of the composite slab.
-
Key words:
- prefabricated /
- composite slab /
- fiber-reinforced composite /
- flexural performance /
- bearing capacity /
- deformation
-
[1] 中华人民共和国住房和城乡建设部. 装配式混凝土结构技术规程:JGJ 1—2014[S] . 北京:中国建筑工业出版社,2014. [2] 叶献国,华和贵,徐天爽,等. 叠合板拼接构造的试验研究[J]. 工业建筑,2010,40(1):59-63. [3] 颜锋,高杰,田春雨,等. 带接缝的混凝土叠合楼板足尺试验研究[J]. 建筑结构,2016,46(10):56-60. [4] 余泳涛,赵勇,高志强. 单缝密拼钢筋混凝土叠合板受弯性能试验研究[J]. 建筑结构学报,2019,40(4):29-37. [5] 恽燕春,陈鹏,王柏生,等. 密拼叠合楼板受力性能研究[J]. 施工技术,2018,47(12):75-79. [6] 林彦,宋健凯,仲崇廷. 不同拼缝构造措施的叠合板受力性能试验研究[J]. 工业建筑,2020,50(6):45-50. [7] 邴卿德,林彦,宋健凯,等. 叠合板加强型密拼拼缝构造及受弯性能有限元分析[J]. 工业建筑,2020,50(9):55-61. [8] 杨悦,姜雪蔚,聂鑫,等. 开槽密拼混凝土叠合板受力性能试验研究[J] . 建筑结构学报,2023,44(7):142-151. [9] 肖彤,张明山,李本悦,等. 叠合板板侧凹槽拼缝连接受弯性能试验研究[J]. 浙江大学学报(工学版),2023,57(4):842-854. [10] 肖宇,李贤. 新型不出筋拼缝混凝土叠合板受弯性能试验研究[J]. 建筑结构,2023,53(5):83-89. [11] 邓旭华,廖桢颖,赵思琪,等. 新型预制拼缝楼板受弯性能试验研究[J]. 湘潭大学学报(自然科学版),2022,44(4):71-80. [12] 廖智强,刘庆文,陈甫亮,等. 不同钢筋斜伸角度下叠合板拼缝试验研究[J]. 建筑科学,2023,39(5):143-151. [13] 何庆锋,胡程群,杨凯华,等. 密拼叠合板拼缝构造及受力性能试验研究[J]. 湖南大学学报(自然科学版),2022,49(3):111-122. [14] 彭亚萍,王文超,金鹏,等. 碳纤维增强复材-混凝土密拼双向叠合楼板静载试验研究[J]. 工业建筑,2022,52(1):205-210. [15] 金鹏. 多因素影响下CFRP-混凝土密拼双向叠合楼板受力性能研究[D]. 上海:上海应用技术大学,2021. [16] 王文超,彭亚萍,恽燕春,等. 碳纤维增强复材-混凝土密拼双向叠合楼板抗弯承载能力分析[J]. 工业建筑,2019,49(9):75-81. [17] 王文超. CFRP-混凝土密拼双向叠合楼板基本受力性能研究[D]. 上海:上海应用技术大学,2021. [18] 李泓霖. 碳纤维增强复材-混凝土密拼双向叠合楼板受力性能及设计方法研究[D]. 上海:上海应用技术大学,2023. [19] 王月昊. 碳纤维复材-混凝土密拼叠合楼板传力机制分析与设计方法[D]. 上海:上海应用技术大学,2023. [20] 王月昊,彭亚萍. 竖向荷载作用下碳纤维增强复材-混凝土密拼双向叠合楼板传力机制分析[J]. 结构工程师,2024,40(4):107-115. [21] AMIRREZA M,DAVOOD M,ELAHEH I. Empirical FRP-concrete effective bond length model for externally bonded reinforcement on the grooves[J]. Composites Part B:Engineering,2019,172:323-338. [22] 中国建筑标准设计研究院. 桁架钢筋混凝土叠合板(60 mm厚度板):15G366-1[S]. 北京:中国计划出版社,2015. -
