Experimental Research on Flexible Pipelines in Soft Soil Foundations Under Uneven Settlement
-
摘要: 软土地基不均匀沉降对埋地管线构成潜在威胁。柔性管道因抗弯刚度低，在不均匀沉降中易变形及破损。通过不均匀沉降作用下软土地基柔性管道模型试验，分析了地基不均匀沉降作用下土压力的变化规律、柔性管道的力学特性，并深入探究了管径和埋深对柔性管道力学响应的影响。结果表明：在6次不均匀沉降作用下，管顶土压力显著增长，管侧土压力最大，土压力系数也随着沉降深度和沉降范围的增加而增大，并确定了土压力系数与沉降深度及范围的非线性表达式，可为评估不均匀沉降作用下柔性管道的受力分析提供理论依据；管道轴向、环向应力和位移随沉降范围与沉降深度增加而增大。即增大管径或减小埋深可有效降低管道应力和位移，因此，在工程设计中应综合考量管径和埋深两个因素的影响。Abstract: Uneven settlement of soft soil foundations poses a potential threat to buried pipelines. Due to their low flexural stiffness， flexible pipelines are particularly prone to deformation and damage during such settlement. Through model tests of flexible pipelines in soft soil foundations under uneven settlement， this paper analyzed the variations in soil pressure and the mechanical characteristics of the pipelines. It further investigated the influence of pipe diameter and burial depth on the mechanical response of flexible pipelines. The results showed that after six cycles of uneven settlement， the soil pressure on the top of the pipeline increased significantly， with the soil pressure on the side of the pipeline reaching the largest. The soil pressure coefficient also increased with the number of settlement cycles. A nonlinear expression was established， relating the soil pressure coefficient to both the settlement depth and range， which can provide a theoretical basis for evaluating the mechanical response of flexible pipelines under uneven settlement. Both axial and circumferential stresses， as well as the displacements of the pipeline， increased with the expansion of the settlement range and the increase in the settlement magnitude. Increasing the pipe diameter or reducing the burial depth can effectively reduce pipeline stress and displacement. Therefore， in engineering design， the combined influence of both pipe diameter and burial depth should be comprehensively considered.
-
Key words:
- soft soil foundation /
- model tests /
- uneven settlement /
- flexible pipeline
-
[1] MARSTON A. The theory of external loads on closed conduits in the light of the latest experiments[J]. Highway Research Board Proceedings，1930，9:138-169. [2] 车宏亚.涵洞和水管结构设计[M].北京:水利电力出版社，1958. [3] 曾国熙.土埧下涵管竖向土压力的计算[J].浙江大学学报（工学版），1960（1）:79-98. [4] 顾安全.上埋式管道及洞室垂直土压力的研究[J].岩石工程学报，1981（1）:3-15. [5] 陈志磊.地基沉陷引起地下PE管道变形破坏的试验与分析[D].太原:太原理工大学，2013. [6] SHMULEVICH I，GALILI N，FOUX A. Soil stress distribution around buried pipes[J]. Journal of Transportation Engineering-ASCE，1986，112（5）:481-494. [7] SHMULEVICH I，GALILI N. Deflections and bending moments in buried pipes[J]. Journal of Transportation Engineering，1986，112（4）:345-357. [8] 张旭.由于地基沉降引起柔性管线的内力和变形的试验研究[D].太原:太原理工大学，2013. [9] WANG F，DU Y J，YANG X M. Physical modeling on ground responses to tunneling in sand considering the existence of HDPE pipes[J]. Geotechnical Testing Journal（GTJ），2015，38（1）:85-97. [10] 周敏，杜延军，王非，等.地层沉陷中埋地HDPE管道力学状态及模型试验分析[J].岩土工程学报，2016（2）:253-262. [11] 周敏，杜延军，王非，等.地层沉陷过程中埋地高密度聚乙烯（HDPE）管道力学行为研究[J].岩石力学与工程学报，2017，36（增刊2）:4177-4187. [12] 周敏.地基不均匀沉降诱发埋地HDPE管道力学响应特征的研究[D].南京:东南大学，2018. [13] 连凯.不均匀沉降下埋地输液管网抗震性能的试验研究[D].唐山:华北理工大学，2017. [14] 刘鹏，黄维和，李玉星，等.连续塌陷下埋地钢管力学响应研究[J].油气储运，2021，40（9）:1017-1026. [15] 刘鹏，黄维和，李玉星，等.阶梯沉降条件下埋地钢管的力学响应规律[J].天然气工业，2023，43（12）:110-120. [16] 刘鹏，张宇，李玉星，等.连续沉降过程中管土相互作用规律[J].油气储运，2024，43（3）:332-341. [17] 孙鹏飞.不均匀地基条件下原水管道受力特征模型试验研究[D].上海:上海工程技术大学，2021. [18] 张炎.地基沉降作用下油气管道力学响应试验研究[D].青岛:中国石油大学（华东），2021. [19] WU H Y，ZHAI K J，FANG H Y，et al. Bell-and-spigot joints mechanical properties study of PCCP under the uneven settlement of foundation:Simulation and full-scale test[J]. Structures，2022，43:1692-1703. [20] 张玉，梁昊，林亮，等.不同沉降方式下埋地管道力学响应试验研究[J].岩土力学，2023，44（6）:1645-1656. [21] 王诗杰.不均匀沉降下埋地长输天然气管道的力学性能研究[D].唐山:华北理工大学，2024. -
