Numerical Simulation-Based Structural Performance of Containment Structures Under Increased Pressurization and Depressurization Rates
-
摘要: 安全壳的主要功能是设备支撑和内外防护,作为核电站的最后一道安全屏障,其对可靠性要求极高,应在整个电厂生命周期内保持结构完整性。为验证安全壳的结构性能,需对其进行打压CTT试验,且该试验具有风险高、时间长的特点。考虑到核电厂的实际需要,期望通过提升CTT试验中的安全壳充卸压速率,以进一步提高其安全性评估效率。采用ANSYS有限元软件,以M310安全壳为研究对象进行数值仿真分析。分别建立两组数值模型,以打压期望速率(充压速率为80 kPa/h,卸压速率为40 kPa/h)和M310安全壳打压实际速率(充压速率为40 kPa/h,卸压速率为14 kPa/h)进行高低速率对比分析,研究速率提升对安全壳结构性能的相关影响。结果表明:充卸压速率提升后壳内压力、气体速度分布均无明显差异;气体温度升降规律相似,两者温差较小;混凝土温度、结构变形均无显著变化。通过仿真分析,验证了速率提升后的安全壳结构性能仍在安全范围内,满足使用需求。Abstract: The main functions of containment structures are equipment support and internal and external protection. As the final safety barrier of a nuclear power plant, the containment structure must meet high reliability requirements, and its structural integrity must be maintained throughout the life cycle of the plant. In order to verify the structural performance of the containment, a CTT test is required, which is characterized by high risk and long duration. Considering the practical needs of nuclear power plants, it is expected that the efficiency of safety assessment can be further improved by enhancing the pressurization and depressurization rates of the containment during the CTT test. Using the ANSYS finite element software, a numerical simulation was conducted with the M310 containment as the research object. Two sets of numerical models were established to compare the expected pressurization rate (pressurization at 80 kPa/h and depressurization at 40 kPa/h) and the actual pressurization rate of the M310 containment (pressurization at 40 kPa/h and depressurization at 14 kPa/h), to investigate the effects of rate inchease on the structural performance of the containment. The results showed that after increasing the pressurization and depressurization rates, there was no significant difference in the pressure and gas velocity distribution inside the containment shell; the gas temperature exhibited similar trends during both heating and cooling, with a relatively small temperature difference between the two processes; there were no significant changes in concrete temperature or structural deformation. The simulation analysis verified that the structural performance of the containment shell remained within the safe range under the increased rate and met the operational requirements.
-
Key words:
- containment /
- CTT test /
- structural performance /
- rate increase /
- numerical simulation
-
[1] 张秉灿,张雄谦. 华龙一号反应堆厂房LOCA事故荷载效应分析研究[C]// 2024年建筑结构技术交流会论文集(第一册). 深圳:2024:191-196. [2] 蔡伟,乐志东,魏婷. 一体化小堆失水事故响应及后果研究[J]. 核动力工程,2024,45(1):149-155. [3] 廖浩仰,明杨,赵富龙,等. LOCA下氦氙气冷反应堆系统安全特性分析[J]. 核动力工程,2024,45(6):197-205. [4] 刘萍萍,刘梦影,徐浩德. 事故容错燃料对核电厂安全影响评价[J]. 核动力工程,2024,45(6):98-105. [5] 张锐,刘帅,冯志鹏,等. LOCA动力分析模型敏感性研究[J]. 中国机械,2024,15:3-9. [6] 刘阳. 核电厂LOCA监测系统可靠性分析及其冗余系统的搭建[J]. 电工技术,2024,13:196-198. [7] 刘建昌,陈韵茵,欧阳勇,等. 压水堆LOCA源项分析方法保守性评价[J]. 核安全,2022,21(5):33-40. [8] 向华伟,熊伯炜,荣华,等. 基于CFD的压水堆安全壳试验速率优化研究[J]. 工业建筑,2025,55(8):193-199. [9] 王定义. 十年大修三大专项试验实施次序分析与优化[C]// 中国电力企业管理创新实践(2021年)论文集. 深圳:中广核核电运营有限公司,2023:451-454. [10] 陈友琼,杨枫. 核电站安全壳整体密封性试验[J]. 电工技术,2022(4):125-128. [11] 常楠,尤坤坤,刘硕,等. 核电安全壳整体密封性试验验证试验方法分析[J]. 电工技术,2023(19):130-131. [12] 郭裕丰,王志永,王洪凯. 安全壳打压试验泄压过程气体流场研究与优化[J]. 电工技术,2024(9):195-197. [13] 刘嘉兴,杨昕光,杨林,等. 充压速率提升后安全壳结构变形分析[C]// 2022年工业建筑学术交流会论文集(中册). 北京:2022:120-123. [14] 杨昕光,褚英杰,荣华,等. 充压速率提升后对安全壳结构的影响性研究[C]// 2021年工业建筑学术交流会论文集,北京:2021:174-177. [15] 国家能源局. 压水堆核电厂钢制安全壳结构整体性试验:NB/T 20431—2017[S]. 北京:中国电力出版社,2017. [16] 国家能源局. 压水堆核电厂预应力混凝土安全壳结构整体性试验:NB/T 20017—2021[S]. 北京:中国电力出版社,2021. [17] ASME. Rules for construction of nuclear facility components section III division 2:code for concrete containments:ASME BPVC-III-2-2019[S]. New York:ASME,2019. [18] ASME. Errata for rules for construction of nuclear facility components section III division 2 code for concrete containments:includes errata 04-427,09-1896,10-634,12-1797,12-1868,11-1551,14-885,14-1001,15-741,15-1963:ASME BPVC-III-2 ERRATA-2015[S]. New York:ASME,2015. -
