平-波钢板组合墙承载力计算与设计方法

栾海涛; 贺雄; 段劲松; 俞果; 侯彦果; 闻陈宝; 朱博莉

doi:10.3724/j.gyjzG25051903

平-波钢板组合墙承载力计算与设计方法

doi: 10.3724/j.gyjzG25051903

1. 北京城建集团有限责任公司, 北京 100088;
2. 清华大学土木工程系, 北京 100084;
3. 北京科技大学未来城市学院, 北京 100083

详细信息

作者简介:
栾海涛,高级工程师,主要从事混凝土和钢结构施工方面研究。Email:2353916282@qq.com

计量
- 文章访问数: 3
- HTML全文浏览量: 1
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2025-05-19
- 网络出版日期: 2026-06-06
- 刊出日期: 2026-04-20

Calculation and Design Methods for the Bearing Capacity of Flat-Corrugated Steel Plate Composite Walls

1. Beijing Urban Construction Group Co., Ltd., Beijing 100088, China;
2. Department of Civil Engineering, Tsinghua University, Beijing 100084, China;
3. School of Future Cities, University of Science and Technology Beijing, Beijing 100083, China

摘要

摘要: 提出了一种新颖的平-波钢板剪力墙，研究了其弹性屈曲性能与稳定承载力设计计算方法。平-波钢板剪力墙由平钢板和波形钢板标准单元连接而成，后者在工厂通过自动化生产线加工而成，因而生产效率高。通过大量算例的有限元数值计算，分别研究了焊接连接型与螺栓连接型平-波钢板剪力墙的受剪弹性屈曲模态、弹性屈曲荷载、破坏模式、失稳机理及弹塑性稳定承载力，其中包含不同参数对屈曲与承载力性能的影响，并提出了受剪稳定承载力设计方法。
- 钢板剪力墙 /
- 剪切弹性屈曲 /
- 受剪承载力
Abstract: This paper proposes a novel flat-corrugated steel plate shear wall （FCSPSW） and explores its elastic buckling performance along with the design and calculation methods for its stability bearing capacity. The FCSPSW is constructed by connecting flat and corrugated steel plate standard units. The latter are fabricated in a factory using a fully available and automatic production line， which ensures high production efficiency. Through the finite element numerical analysis of a large number of examples， the shear elastic buckling modes， elastic buckling loads， failure modes， instability mechanisms， and stability bearing capacity prediction for both welded and bolted connection types of FCSPSWs were studied respectively. This numerical investigation revealed the influence of different design parameters on the buckling and bearing capacity. Finally， design methods for predicting the shear stability bearing capacity of two types of FCSPSWs were proposed.
- steel plate shear wall /
- shear elastic buckling /
- shear-bearing capacity

HTML全文

参考文献(15)

[1]	ASTANEH-ASL A. Seismic behavior and design of steel shear walls［R］. Berkeley：Structural Steel Educational Council，2001.
[2]	郭彦林，朱靖申. 剪力墙的型式、设计理论研究进展［J］. 工程力学，2020，37（6）：19-33.
[3]	孙军浩，赵秋红. 钢板剪力墙的工程应用［J］. 建筑结构，2015，45（16）：63-70.
[4]	中华人民共和国住房和城乡建设部. 高层民用建筑钢结构技术规程：JGJ 99—2015［S］. 北京：中国建筑工业出版社，2015.
[5]	中国工程建设标准化协会. 波形钢板结构技术规程：T/ CECS 290—2022［S］. 北京：中国计划出版社，2022.
[6]	SUN H，GUO Y，WEN C，et al. Local and global buckling prevention design of corrugated steel plate shear walls［J］. Journal of Building Engineering，2023，68：106055.
[7]	中华人民共和国住房和城乡建设部. 钢结构设计标准：GB 50017—2017［S］. 北京：中国建筑工业出版社，2018.
[8]	ZHAO Q，SUN J，LI Y，et al. Cyclic analyses of corrugated steel plate shear walls［J］. The Structural Design of Tall and Special Buildings，2017，26（16）：1-17.
[9]	WEN C，GUO Y，ZUO J，et al. Global shear stability capacity of trapezoidally corrugated steel plate shear walls with boundary elements［J］. Journal of Building Engineering，2023，72：106553.
[10]	TIMOSHENKO S P. On the correction for shear of the differential equation for transverse vibrations of prismatic bars［J］. Philosophical Magazine，1921，41：744-746.
[11]	TIMOSHENKO S P. On the transverse vibrations of bars of uniform cross-section［J］. Philosophical Magazine，1922，43（253）：125-131.
[12]	DOU C，PI Y，GAO W. Shear resistance and post-buckling behavior of corrugated panels in steel plate shear walls［J］. Thin-Walled Structures，2018，131：816-826.
[13]	左佳奇. 单元式波形钢板剪力墙设计理论与试验研究［D］. 北京：清华大学，2023.
[14]	EASLEY J T，MCFARLAND D E. Buckling of light-gage corrugated metal shear diaphragms［J］. Journal of the Structural Division，1969，95：1497-1516.
[15]	EASLEY J T. Buckling formulas for corrugated metal shear diaphragms［J］. Journal of the Structural Division，1975，101（7）：1403-1417.
