Analysis of the Influence of Tension-Compression Stiffness Difference in CFST Members on a 385 m High Long-Span Tower
-
摘要: 随着跨越能力和线路净空要求提高，大跨越塔的高度随之增高，具有高承载力、高塑性韧性、高抗震性能和施工便捷等优点的钢管混凝土结构逐渐被应用于大跨越输电塔结构设计中。基于500 kV凤城—梅里长江大跨越输电塔，利用不同有限元软件计算结果进行对比，验证了钢管混凝土输电塔模型的准确性。分析发现，若不考虑钢管混凝土构件拉压刚度差异，杆塔设计结果偏于不安全。设计时应取拉压等刚度和拉压不等刚度两种模型内力计算结果的包络值，确保设计结果安全可靠。Abstract: With increasing demands for crossing capacity and line clearance， the height of long-span transmission towers has risen accordingly. Concrete-filled steel tubular （CFST） structures， which offer advantages such as high bearing capacity， good ductility， strong seismic performance， and ease of construction， are being gradually adopted in the design of long-span transmission towers. Based on the super-high tower used in the 500 kV Fengcheng—Meili project， this study compares calculation results obtained from different finite element software packages and verifies the accuracy of the CFST tower model. The analytical results indicate that if the difference in tensile and compressive stiffness of CFST members is not considered， the design of the tower may be unsafe. To ensure a safe and reliable design， envelope values of internal force calculation results should be derived from both equal-stiffness and unequal-stiffness models.
-
Key words:
- long span /
- CFST members /
- tensile stiffness /
- compressive stiffness /
- numerical simulation
-
[1] DREW A． 1901 transmission line the great carquinez straits crossing（History）[J]. IEEE Power and Energy Magazine，2010，8（3）:80-88． [2] 邵帅，杨风利，程永锋，等.大跨越输电高塔发展历程及其结构承载性能研究综述[J].中国电机工程学报，2022，42（增刊1）:313-331. [3] 杨元春，张克宝.输电跨越塔设计回顾与展望[J].特种结构，2006（3）:70-76. [4] 石华军，胡列翔，叶尹，等.钢管混凝土构件在输电线路大跨越铁塔中的应用[J].电力建设，2011，32（3）:5-8. [5] 蔡钧，杨元春，左元龙.江阴长江大跨越铁塔构件和节点设计[J].电力勘测设计，2018（11）:55-59. [6] 黄爱华，董建尧，袁崇毅，等. 500 kV马鞍山大跨越工程跨越塔电梯的设计与应用[J].电力建设，2008（3）:36-39. [7] 韩林海.钢管混凝土结构:理论与实践[M]. 3版.北京:科学出版社，2016:1-12. [8] WANG W D，SHI Y L，JI S H，et al. Experimental and numerical investigations of steel-reinforced concrete-filled steel tubular members under compression-bending-shear loads[J]. Journal of Constructional Steel Research，2021，181:106609. [9] 孟宪乔，王静峰，程安乐，等.大跨越输电铁塔结构设计与计算分析[J].工程与建设，2023，37（2）:507-511. [10] 余亮，宁帅朋，龙海波，等.凤城—梅里长江大跨越工程基础设计及关键技术研究[J].电力勘测设计，2023（5）:12-18. [11] HAMIDIAN M R，JUMAAT M Z，ALENGARAM U J，et al． Pitch spacing effect on the axial compressive behaviour of spirally reinforced concrete filled steel tube（SRCFT）[J] ． Thin-Walled Structures，2016，100:213-223. [12] 万城勇，查晓雄．配筋钢管混凝土轴压短柱受力性能试验研究[J] ．建筑结构学报，2013，34（1）:259-266. -
