Seismic Performance-Based Design and Analysis of a Large Cantilevered High-Rise Building Structure
-
摘要: 某大悬挑高层建筑结构地上5层,地下1层,建筑高度26.2 m,采用框架-剪力墙结构体系,具有扭转不规则、楼板不连续、构件间断共3项超限不规则项。针对结构超限情况,设定了相应的抗震性能目标和加强措施。采用YJK、MIDAS Building和SAUSAGE三款软件对结构进行了多遇地震和风作用下的弹性分析、设防地震及罕遇地震作用下的等效弹性分析及罕遇地震作用下的弹塑性时程分析。针对楼板不连续、构件间断等超限不规则项进行了楼板应力、悬挑跃层桁架性能及穿层柱屈曲分析,并补充了楼板舒适度分析。计算结果表明,采取合理的加强措施后,结构各项指标均满足相关规范要求,能够达到预设的抗震性能目标。Abstract: This study focuses on a large cantilevered high-rise structure with a height of 26.2 m, which adopts a frame-shear wall structural system. The structure exhibits three out-of-code irregularities, including torsional irregularity, discontinuous floors, and component interruption. Specific seismic performance objectives and strengthening measures were established for these irregularities. The structure was analyzed using YJK, MIDAS Building, and SAUSAGE software, conducting elastic analysis under frequent earthquakes and wind loads, equivalent elastic analysis under fortification and rare earthquakes, as well as elasto-plastic time-history analysis under rare earthquakes. Structural analyses were performed to address key irregular features, such as discontinuous floor slabs, and discontinuous members. These included stress analysis of floor slabs, performance evaluation of cantilevered skip-floor trusses, and buckling analysis of cross-story columns, supplemented with a floor comfort assessment. The calculation results demonstrates that, with appropriate strengthening measures, all structural indicators met the code requirements and achieve the predefined seismic performance objectives. The design methodology and measures adopted can serve as a reference for similar projects. The design methods and strengthening measures employed can serve as a reference for similar projects.
-
[1] 中华人民共和国住房和城乡建设部.建筑工程抗震设防分类标准:GB 50223—2008[S].北京:中国建筑工业出版社,2008. [2] 中华人民共和国住房和城乡建设部.建筑结构荷载规范:GB 50009—2012[S].北京:中国建筑工业出版社,2012. [3] 中华人民共和国住房和城乡建设部.工程结构通用规范:GB 55001—2021[S].北京:中国建筑工业出版社,2021. [4] 中华人民共和国住房和城乡建设部.高层建筑混凝土结构技术规程:JGJ 3—2010[S].北京:中国建筑工业出版社,2010. [5] 中华人民共和国住房和城乡建设部.建筑抗震设计规范:GB 50011—2010[S].北京:中国建筑工业出版社,2016. [6] 中国国家标准化管理委员会.中国地震动参数区划图:GB 18306—2015[S].北京:中国标准出版社,2015. [7] 武汉市城乡建设局,武汉市地震局.关于提高武汉市部分新建建筑工程抗震设防要求的通知:武城建[2021] 41号[A].武汉:武汉市城乡建设局,武汉市地震局,2021. [8] 李春光,陈健,王晓梅,等.陕西文化创意国际大厦连体结构设计[J].建筑结构,2023,53(22):47-51. [9] 李林,王安梅,周忠发,等.某隔震建筑连廊结构设计与分析[J].建筑结构,2023,53(18):108-112. [10] 沈捷攀,朱浩川,郑晓清,等.杭州某连体高层创伤中心抗震设计[J].建筑结构,2023,53(20):66-71. [11] 苗伟.台州某商业广场超长结构及大悬挑设计[J].建筑结构,2023,53(13):57-61. [12] 曹万林,张元,边瑾靓,等.高空大悬挑主桁架式钢模架受力性能试验研究[J].建筑结构,2021,51(9):120-127. [13] 刘建飞,周袁凯,蒋航军,等.大悬挑知识产权出版社业务楼抗震设计[J].建筑结构,2019,49(增刊2):306-310. [14] 中华人民共和国住房和城乡建设部.超限高层建筑工程抗震设防专项审查技术要点:建质[2015] 67号[A].北京:中华人民共和国住房和城乡建设部,2015. [15] 北京盈建科软件股份有限公司. YJK-A建筑结构计算软件用户手册[Z].北京:北京盈建科软件股份有限公司,2023. [16] 中华人民共和国住房和城乡建设部.混凝土结构设计标准:GB/T 50010—2010[S].北京:中国建筑工业出版社,2024. [17] 广州建研数力建筑科技有限公司. PKPM-SAUSAGE用户手册[Z].广州:广州建研数力建筑科技有限公司,2022. [18] 中华人民共和国住房和城乡建设部.钢结构设计标准:GB 50017—2017[S].北京:中国建筑工业出版社,2018. [19] 中华人民共和国住房和城乡建设部.建筑楼盖结构振动舒适度技术标准:JGJ/T 441—2019[S].北京:中国建筑工业出版社,2019. -
