基于钢框架耗能减震需求的外置位移放大式自复位耗能机构研究

王正川; 连鸣

doi:10.3724/j.gyjzG24120304

基于钢框架耗能减震需求的外置位移放大式自复位耗能机构研究

doi: 10.3724/j.gyjzG24120304

王正川¹,
连鸣^1,2, ,

1. 西安建筑科技大学土木工程学院, 西安 710055;
2. 西安建筑科技大学结构工程与抗震教育部重点实验室, 西安 710055

基金项目:

国家自然科学基金项目（52478205）。

详细信息

作者简介:
王正川，硕士，主要从事可恢复功能钢结构体系抗震性能的研究工作。

通讯作者:
连鸣，博士，教授，博士生导师，主要从事可恢复功能钢结构体系抗震机理与设计方法方面的研究工作，lianming@xauat.edu.cn。

计量
- 文章访问数: 22
- HTML全文浏览量: 7
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2024-12-03
- 网络出版日期: 2026-07-06

Research on External Displacement-Amplification Self-Resetting Energy Dissipation Mechanism Based on the Energy Dissipation and Damping Requirements of Steel Frames

WANG Zhengchuan¹,
LIAN Ming^{1,2
, ,}

1. School of Civil Engineering, Xi'an University of Architecture and Technology, Xi'an 710055, China;
2. Key Lab of Structural Engineering and Earthquake Resistance, Ministry of Education, Xi'an University of Architecture and Technology, Xi'an 710055, China

摘要

摘要: 已有位移型阻尼器的位移放大机构常布置于钢框架的层间，但结构层间位移有限且位移型阻尼器在经历大位移后存在显著的残余变形。为解决上述问题，将位移放大装置和摩擦型自复位阻尼器相结合，提出了位移放大式自复位耗能机构（EDAS），该机构通过跨楼层并外置于结构外立面的形式与钢框架连接。首先介绍了EDAS的基本构造和工作原理，推导了EDAS的位移放大系数γ计算公式。随后建立了安装EDAS钢框架和传统钢框架子结构的有限元模型，对比了两者的滞回性能，并通过安装EDAS钢框架子结构有限元模型的参数分析，验证了所提γ计算公式的准确性。结果表明：EDAS可有效放大摩擦型自复位阻尼器的耗能能力，使EDAS兼具高耗能与自复位能力；安装EDAS可显著提升钢框架的耗能与震后残余变形控制能力；参数分析结果表明所提出的γ计算公式具有较高的准确性。
- 位移放大 /
- 钢框架 /
- 耗能减震 /
- 自复位 /
- 数值模拟
Abstract: Displacement amplification mechanisms for existing displacement-dependent dampers are typically arranged between the inter-story spaces of steel frames， but the inter-story displacement of the structure is limited， and such dampers exhibit significant residual deformation after experiencing large displacements. To address these issues， a displacement amplification device was combined with a friction-based self-resetting damper to propose the external displacement amplification self-resetting energy dissipation system （EDAS）， which is connected to the frame in an inter-story， externally mounted configuration on the building facade. The basic structure and working principle of EDAS were first introduced， and the formula for calculating the displacement amplification coefficients of EDAS was derived. Finite element models of steel frames with EDAS installed and traditional steel frame substructures were subsequently developed to compare their hysteretic performance. Through parametric analysis of the finite element model of the EDAS-installed steel frame substructure， the accuracy of the proposed displacement amplification coefficient formula was validated. The results show that EDAS can effectively enhance the energy dissipation capacity of friction-based self-resetting dampers， giving EDAS both high energy dissipation and self-resetting capabilities. Installing EDAS significantly improves the energy dissipation and post-earthquake residual deformation control of steel frames. The parametric analysis results confirm the high accuracy of the proposed displacement amplification coefficient formula.
- displacement amplification /
- steel frame /
- energy dissipation and damping /
- self-resetting /
- numerical simulation

HTML全文

参考文献(18)

[1]	郑国足，韩建平.轴向拉压式U型厚壁金属波纹管阻尼器抗震性能研究[J].地震工程学报，2024，46（6）:1318-1330.
[2]	郁银泉，马晓飞，张爱林，等.带环形阻尼器的装配式高强钢板剪力墙抗震性能研究[J].工程力学，2023，40（6）:28-36.
[3]	赵志远，王燕，张海宾.带有转动摩擦阻尼器的钢框架结构的力学性能研究[J].工业建筑，2023，53（6）:138-147.
[4]	CONSTANTINOU M C，TSOPELAS P，HAMMEL W，et al.Toggle-brace-damper seismic energy dissipation systems[J].Journal of Structural Engineering，2001，127（2）:105-112.
[5]	岳焱超，陈唐兵，王雁，等.套索式黏滞阻尼器位移放大系数的理论和实验研究[J].应用力学学报，2019，36（6）:1334-1339.
[6]	兰炳稷，何浩祥，王宝顺.局部肘节消能装置的减振机制分析及其优化控制[J].建筑结构学报，2022，43（7）:32-43.
[7]	RIBAKOV Y，GLUCK N.Practical design of MDOF structures with supplemental viscous dampers using mechanical levers[C]//Proceedings of the 8th ASCE Specialty Conference on Probabilistic Mechanics and Structural Reliability.Washington:2000.
[8]	RIBAKOV Y，REINHORN A M.Design of amplified structural damper using optimal considerations[J].Journal of Structural Engineering，2003，129（10）:1422-1427.
[9]	KANG J D，TAGAWA H． Seismic performance of steel structures with seesaw energy dissipation system using fluid viscous dampers[J].Engineering Structures，2013，56:431-442.
[10]	王德斌，张昕岳，付兴，等.旋转放大型摩擦自复位支撑性能试验及恢复力模型验证[J].振动与冲击，2024，43（9）:8-17.
[11]	刘文光，胡乐梅，许浩，等.增位型阻尼墙力学模型及跨层减震结构的地震响应分析[J].工程力学，2021，38（7）:197-206.
[12]	吴思远，廖旭钊，荣坤杰，等.3种构造形式调谐质量阻尼器性能[J].同济大学学报（自然科学版），2024，52（9 ）:1401-1408.
[13]	邱灿星，刘家旺，杜修力.SMA滑动摩擦阻尼器的数值模拟及参数分析[J].工程力学，2022，39（8）:69-79.
[14]	王建军，韩建平，许继祥.带环形弹簧的自复位摩擦阻尼器滞回性能理论及有限元分析[J/OL].工程力学，2026[ 2026-03-19].https://link.cnki.net/urlid/11.2595.o3.20240515.1158.008.
[15]	陈云，陈超，徐子凡.具有自复位功能的金属耗能阻尼器抗震性能研究[J].振动与冲击，2021，40（23）:25-31.
[16]	NAEEM A，MAIDA Y，KOICHI K，et al.Development and experimental verification of self-centering disc slit damper for buildings[J].Journal of Constructional Steel Research，2023，201:107759.
[17]	李俊霖，王伟，沈德阳，等.基于高强钢碟簧和复合摩擦材料的自复位消能减震阻尼器受力性能与试验研究[J].建筑结构学报，2021，42（增刊1）:122-131.
[18]	周颖，田文博，王睿，等.自复位剪力墙的三水准抗震设防与四水准抗震设防对比研究[J].建筑结构学报，2021，42（1）:67-77.
