分段控制型全钢支撑滞回性能研究

辛力; 李佳珂; 张龙; 连鸣; 程倩倩; 史生志

doi:10.3724/j.gyjzG24112103

分段控制型全钢支撑滞回性能研究

doi: 10.3724/j.gyjzG24112103

辛力¹,
李佳珂²,
张龙²,
连鸣^2,3, ,,
程倩倩¹,
史生志¹

1. 中国建筑西北设计研究院有限公司, 西安 710018;
2. 西安建筑科技大学土木工程学院, 西安 710055;
3. 西安建筑科技大学结构工程与抗震教育部重点实验室, 西安 710055

基金项目:

陕西省科协青年人才托举计划项目（20230426）；中建股份科技研发课题（CSCEC-2023-Z-18，CSCEC-2025-Z-22）；陕西省秦创原“科学家+工程师”队伍建设（2022KXJ-084）。

详细信息

作者简介:
辛力，博士，正高级工程师，主要从事新型建筑减隔震产品设计及研发，28395099@qq.com。

通讯作者:
连鸣，博士，教授，博士生导师，主要从事可恢复功能钢结构体系抗震机理与设计方法方面的研究，lianming@xauat.edu.cn。

计量
- 文章访问数: 19
- HTML全文浏览量: 6
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2024-11-21
- 网络出版日期: 2026-07-06

Research on the Hysteretic Performance of Sectional Control-Type Steel Braces

1. China Northwest Building Design and Research Institute Co., Ltd., Xi'an 710018, China;
2. School of Civil Engineering, Xi'an University of Architecture and Technology, Xi'an 710055, China;
3. Key Lab of Structural Engineering and Earthquake Resistance, Ministry of Education, Xi'an University of Architecture and Technology, Xi'an 710055, China

摘要

摘要: 为了充分发挥传统钢支撑刚度大的优势，提升其变形能力和滞回性能，优化传统屈曲约束支撑施工不方便等问题，提出一种新型分段控制型全钢支撑。采用ABAQUS有限元软件建立了数值模型，并通过该新型支撑拟静力试验验证了模型的准确性。与传统钢支撑性能进行对比，深入研究了新型分段控制型全钢支撑的滞回性能。通过参数分析研究了初始缺陷、耗能段长度、耗能段截面尺寸、弹性段截面尺寸对支撑滞回性能的影响规律。分析结果表明：该新型支撑具有良好的变形能力和滞回性能，且对初始缺陷变化不敏感；随着耗能段长度的减小，支撑承载力、刚度、耗能能力均有所提升，但是耗能段长度过小会导致支撑提前破坏，建议两端耗能段占总长度的比例为0.3~0.4；该支撑的滞回性能受耗能段截面尺寸影响最大，截面尺寸的增加将显著提升支撑的承载力、刚度、耗能能力等；弹性段截面尺寸不宜过大，否则会导致支撑提前破坏或出现刚度退化现象，建议耗能段与弹性段的面积比值为0.3~0.4。
- 分段控制 /
- 新型支撑 /
- 有限元分析 /
- 滞回性能 /
- 参数分析
Abstract: An innovative sectional control-type steel brace （SCTS） was developed to fully utilize the advantages of traditional steel braces， such as their high stiffness， while effectively enhancing deformation and hysteretic performance， and addressing the construction inconveniences associated with traditional buckling-restrained braces. A numerical model of the SCTS was established adopting ABAQUS finite element software， and its accuracy was verified through a quasi-static test. The hysteretic performance of the SCTS was investigated in detail and compared with that of a traditional steel brace. A parametric study was conducted to analyze the influence of initial imperfection， length of the energy dissipation section， cross-sectional dimensions of the energy dissipation section， and cross-sectional dimensions of the elastic section on the hysteretic performance of the SCTS. The results showed that the SCTS exhibited excellent deformation capacity and hysteretic performance. The performance of the SCTS was not sensitive to variations in initial imperfection. As the length of the energy dissipation section decreased， the bearing capacity， stiffness， and energy dissipation capacity increased. However， an excessively short energy dissipation section could lead to premature failure of the SCTS. Therefore， it is recommended that the ratio of the combined length of the two end energy dissipation sections to the total length should be between 0.3 and 0.4. The hysteretic performance of the SCTS was most affectd by the cross-sectional dimensions of the energy dissipation section. Increasing these dimensions significantly enhanced the bearing capacity， stiffness， and energy dissipation capacity. Conversely， an overly large cross-section for the elastic section could lead to premature failure or stiffness degradation. Thus， the recommended ratio of the cross-sectional area of the energy dissipation section to that of the elastic section should be between 0.3 and 0.4.
- sectional control /
- innovative brace /
- finite element analysis /
- hysteretic performance /
- parametric analysis

HTML全文

参考文献(24)

[1]	SEN A D，SWATOSH M A，BALLARD R，et al.Development and evaluation of seismic retrofit alternatives for older concentrically braced frames[J].Journal of Structural Engineering，2017，143（5）:04016232.
[2]	董志骞，李钢，李宏男.多层中心支撑钢框架结构抗震性能简化评估方法[J].建筑结构学报，2018，39（5）:1-9.
[3]	HAN S W，KIM W T，FOUTCH D A，et al.Seismic behavior of HSS bracing members according to width-thickness ratio under symmetric cyclic loading[J].Journal of Structural Engineering，2007，133（2）:264-273.
[4]	TREMBLAY R.Inelastic seismic response of steel bracing members[J].Journal of Constructional Steel Research，2002，58（5/6/7/8）:665-701.
[5]	FELL B V，KANVINDE A M，DEIERLEIN G G，et al.Experimental investigation of inelastic cyclic buckling and fracture of steel braces[J].Journal of Structural Engineering，2009，135（1）:19-32.
[6]	吴徽，张国伟，赵健，等.防屈曲支撑加固既有RC框架结构抗震性能研究[J].土木工程学报，2013，46（7）:37-46.
[7]	于敬海，郑达辉，胡相宜，等.方钢管混凝土组合异形柱防屈曲支撑框架抗性能试验[J].天津大学学报（自然科学与工程技术版），2018，51（增刊1）:135-142.
[8]	TREMBLAY R，BOLDUC P，NEVILLE R，et al.Seismic testing and performance of buckling-restrained bracing systems[J].Canadian Journal of Civil Engineering，2006，33（2）:183-198.
[9]	USAMI T，GE H B，KASAI A.Overall buckling prevention condition of buckling-restrained braces as a structural control damper[C]//Proceeding of the 14th World Conference on Earthquake Engineering.Beijing:2008.
[10]	郭彦林，王小安.一种四角钢组合约束型防屈曲支撑的外围约束机理及刚度取值研究[J].土木工程学报，2012（11）:79-87.
[11]	姜子钦，郭彦林，张博浩，等.双矩管装配式防屈曲支撑设计理论研究[J].工程力学，2015（6）:41-51.
[12]	王小安，郭彦林，姜子钦，等.一种四槽钢组合约束型防屈曲支撑的外围约束机理与约束刚度取值研究[J].建筑钢结构进展，2013，15（3）:1-11.
[13]	郭亚楠，高向宇，凌利改，等.多段连接防屈曲支撑设计及试验研究[J].钢结构，2017，32（7）:6-11.
[14]	SUN J B，PAN P，WANG H S． Development and experimental validation of an assembled steel double-stage yield buckling restrained brace[J].Journal of Constructional Steel Research，2018，145:330-340.
[15]	BARBAGALLO F，BOSCO M，MARINO E M，et al． Achieving a more effective concentric braced frame by the double stage yield BRB[J].Engineering Structures，2019，186:484-497.
[16]	姜涛.新型纯钢屈曲约束支撑耗能性能研究[D].哈尔滨:中国地震局工程力学研究所，2017.
[17]	郑国足，韩建平.新型切口厚壁钢管耗能支撑抗震性能研究及参数分析[J].工程力学，2024，41（9）:201-213.
[18]	任炜晨，赵宝成，徐伟栋，等.不锈钢耗能板双层方钢防屈曲支撑滞回性能研究[J/OL].工业建筑，2024[ 2024-09-05].http://kns.cnki.net/kcms/detail/11.2068.TU.20240905.1057.002.html.
[19]	王涛，潘雨桐，孟丽岩，等.双阶自复位防屈曲支撑滞回性能参数分析[J].建筑钢结构进展，2024，26（12）:35-50.
[20]	高晨啸，陈向荣，王欣淼，等.短屈服段屈曲约束支撑的滞回性能研究[J].西安建筑科技大学学报（自然科学版），2023，55（6）:819-826.
[21]	蔡亮，杨金栋，林楷奇，等.两阶段受力可调控的屈曲约束支撑牺牲连接组件试验研究[J/OL].工程力学，2024[ 2024-04-23].http://kns.cnki.net/kcms/detail/11.2595.o3.20240422.1948.010.html.
[22]	李亮，牛飞宇，黄俊，等.圆形截面并联式屈曲约束支撑设计方法及力学性能[J].工程力学，2026，43（1）:97-108.
[23]	中华人民共和国住房和城乡建设部.建筑抗震试验规程:JGJ/T 101—2015[S].北京:中国建筑工业出社，2015.
[24]	中华人民共和国住房和城乡建设部.高层民用建筑钢结构技术规程:JGJ 99—2015[S].北京:中国建筑工业出版社，2015.
