单肢连接角钢玻纤增强聚氨酯（GRPU）无损加固后承压性能提升效果研究

徐彬; 邱俊霞; 龚正轩; 冯衡; 曾二贤; 张志伟; 钱宏亮; 王化杰

doi:10.3724/j.gyjzG24103103

单肢连接角钢玻纤增强聚氨酯（GRPU）无损加固后承压性能提升效果研究

doi: 10.3724/j.gyjzG24103103

1. 中国电力工程顾问集团中南电力设计院有限公司, 武汉 430061;
2. 哈尔滨工业大学土木工程学院, 哈尔滨 150001;
3. 哈尔滨工业大学(威海)土木工程系, 山东威海 264209

详细信息

作者简介:
徐彬,硕士,高级工程师,主要从事输电线路杆塔设计和基础设计工作。

通讯作者:
邱俊霞,博士研究生,Junxia_Qiu@163.com。

计量
- 文章访问数: 1
- HTML全文浏览量: 0
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2024-10-31
- 网络出版日期: 2026-06-06
- 刊出日期: 2026-04-20

Research on the Enhancement of Compressive Performance in GRPU Non-Destructively Reinforced Single-Limb Angle Connections

1. Central Southern China Electric Power Design Institute Co., Ltd. of China Power Engineering Consulting Group, Wuhan 430061, China;
2. School of Civil Engineering, Harbin Institute of Technology, Harbin 150001, China;
3. Department of Civil Engineering, Harbin Institute of Technology at Weihai, Weihai 264209, China

摘要

摘要: 随着电网规模的不断扩大和电力需求的日益增长，输电塔的荷载需求会不断增大，对其关键构件进行无损加固研究对提升其结构功能、延长其使用寿命具有重要的理论意义和应用价值。以轻质高强的玻纤增强聚氨酯（GRPU）替代传统加固中的钢材，以输电塔常用的斜材角钢（单肢连接角钢）为对象，基于无损双侧加固方案，建立了单肢连接角钢加固前后的精细化有限元模型，设计并开展了单肢连接角钢承压试验，验证了有限元模拟的可行性和准确性；分析了加固比和构件长细比两个参数对单肢连接角钢加固构件破坏模式和承载能力的影响，揭示了GRPU无损加固方案的加固机理。结果表明：加固材可以限制构件扭转变形，提升构件抗弯刚度，从而提升构件承载力；随着角钢长细比、加固比增大，加固效果不断增大。最后，给出了单肢连接角钢的加固比取值建议。
- 输电塔 /
- 单肢连接角钢 /
- GRPU /
- 无损加固 /
- 有限元分析 /
- 抗压能力
Abstract: With the continuous expansion of the power grid scale and the increasing demand for electricity， the load demand of transmission towers continues to rise. Studying the non-destructive reinforcement of their key components is of great theoretical significance and practical value for improving their structural function and extending their service life. Lightweight and high-strength glass-fiber reinforced polyurethane （GRPU） is used to replace steel in traditional reinforcement， and the inclined angle （single-limb angle） commonly used in transmission towers is selected as the research object. A refined finite element model of the single-limb angle before and after reinforcement was established based on the non-destructive double-sided reinforcement scheme. A compression test of the single-limb angle was designed and conducted to verify the accuracy of the finite element simulation， and the effects of the two parameters， namely reinforcement ratio and slenderness ratio. were investigated. The effects of reinforcement ratio and slenderness ratio on the failure mode and bearing capacity of reinforced single-limb angle components were analyzed， and the reinforcement mechanism of the GRPU non-destructive reinforcement scheme was revealed. The results showed that the reinforcement limited the torsional deformation of the components and improved their bending stiffness， thereby enhancing the bearing capacity of the members； with the increase of the slenderness ratio and reinforcement ratio， the reinforcement effect continued to improve. Finally， a reinforcement ratio for single-limb angles was proposed.
- transmission tower /
- single-limb angle /
- GRPU /
- non-destructive reinforcement /
- finite element analysis /
- compressive capacity

HTML全文

参考文献(23)

[1]	常政刚，庄艳秋，董伟. 输电塔带电加固技术研究与工程应用［C］// 中国机电一体化技术应用协会·第四届全国石油和化工电气设计与应用论文大赛论文集. 淄博：2020.
[2]	LIANG G，WANG L T，LIU Y H，et al. Mechanical behavior of steel transmission tower legs reinforced with innovative clamp under eccentric compression［J］. Engineering Structures，2022，258：1-18.
[3]	刘云贺，辛振科，梁刚，等. 角钢T形组合截面压弯构件受力性能试验研究［J］. 建筑结构，2022，52（24）：57-63.
[4]	辛振科. 双角钢T形组合截面压弯构件受力性能及设计方法研究［D］. 西安：西安理工大学，2022.
[5]	XIN Z K，WEI H H，LIU Y H，et al. Study on mechanical properties of press-bending members based on transmission towers diagonal angle reinforcement in-situ［J］. International Journal of Steel Structures，2022，22（4）：1025-1041.
[6]	梁刚，李桂花，耿娜娜，等. 基于新型夹具的双角钢十字组合构件偏压承载力研究［J］. 自然灾害学报，2022，31（6）：113-124.
[7]	TEMPLE M C，SAKLA S S S，STCHYRBA D，et al. Arrangement of interconnectors for starred angle compression members［J］. Canadian Journal of Civil Engineering，1994，21（1）：110348977.
[8]	JULIE E M，MA X，YAN Z. Experimental study on multi-panel retrofitted steel transmission towers［J］. Journal of Constructional Steel Research，2012，78：58-67.
[9]	JIAN X Y，LIU H Q，ZHAO Z W，et al. A study of the mechanical behavior of rectangular steel tubular column strengthened using intermittent welding angle steel［J］. Structures，2021，33：3298-3310.
[10]	孙启刚，吴健，刘海涛，等. 输电塔T形组合角钢加固构件承载性能试验研究［J］. 工业建筑，2018，48（12）：181-186.
[11]	KOMATSU H，ISHII K，FUKUSHIMA A. Experimental study on buckling strength of angle steel compression members with Built-up Bracing［J］. Kou Kouzou Rombunshuu，2009，16（62）：27-34.
[12]	WANG J T，WU X H，YANG B，et al. Retrofitted built-up steel angle members for enhancing bearing capacity of latticed towers:experiment［J］. Steel and Composite Structures，2021，41（5）：681-695.
[13]	李艳丽，石磊，武振宇，等. 采用箱形截面加固的输电塔主杆角钢承载能力的有限元参数分析［J］. 工业建筑，2022，52（8）：41-47.
[14]	李文斌，邱智育，马池，等. 输电线路杆塔非焊接Y字形加固技术试验研究［J］. 工业建筑，2020，50（8）：120-127.
[15]	谢强，孙力，张勇. 500kV输电塔结构抗冰加固改造方法试验研究［J］. 中国电机工程学报，2011，31（16 ）：108-114.
[16]	张戬，杨正，谢强. 输电塔T形组合角钢加固方法试验研究［J］. 工业建筑，2019，49（4）：37-43.
[17]	XIE Q，ZHANG J. Experimental study on failure modes and retrofitting method of latticed transmission tower［J］. Engineering Structures，2021，226：1-14.
[18]	CHEN C，TANG Y，ZHANG L，et al. Analysis of the bearing capacity of a steel structural member after reinforcement［J］. Advances in Civil Engineering，2022，2022：1-14.
[19]	全国钢标准化技术委员会. 金属材料拉伸试验第1部分：室温试验方法：GB/T 228.1—2021 ［S］. 北京：中国标准出版社，2021.
[20]	全国纤维增强塑料标准化技术委员会. 纤维增强塑料性能试验方法总则：GB/T 1446—2005［S］. 北京：中国标准出版社，2005.
[21]	全国纤维增强塑料标准化技术委员会. 纤维增强塑料拉伸性能试验方法：GB/T 1447—2005［S］. 北京：中国标准出版社，2005.
[22]	国家能源局. 架空输电线路杆塔结构设计技术规定：DL/T 5154—2012［S］. 北京：中国标准出版社，2012.
[23]	American Society of Civil Engineers. Design of latticed steel transmission structures:A SCE 10-2015［S］. Newyork：American Society of Civil Engineers，2015.
