基于建筑热工设计分区的风驱雨渗水气候风险评估方法

黄凌江; 史文璇

doi:10.3724/j.gyjzG24092802

基于建筑热工设计分区的风驱雨渗水气候风险评估方法

doi: 10.3724/j.gyjzG24092802

武汉大学建筑系, 武汉 430072

基金项目:

国家重点研发计划（2022YFC3801600）。

详细信息

作者简介:
黄凌江，教授，主要从事建筑设计及其理论和建筑技术科学方向研究。电子信箱：huanglj@whu.edu.cn

计量
- 文章访问数: 30
- HTML全文浏览量: 8
- PDF下载量: 3
- 被引次数: 0
出版历程
- 收稿日期: 2024-09-28
- 网络出版日期: 2026-04-11
- 刊出日期: 2026-03-20

A Method for Wind-Driven Rainwater Infiltration Climate Risk Assessment Based on Building Thermal Design Zoning

Department of Architecture, Wuhan University, Wuhan 430072, China

摘要

摘要: 风驱雨是导致外墙渗水的主要外部因素，而我国各地区风驱雨气候条件存在显著差异。研究提出了一种结合建筑热工设计分区的风驱雨渗水气候风险评价方法和指标。通过该指标对现有建筑热工设计分区的主要城镇的风驱雨渗水风险等级进行评价并绘制了全国风驱雨渗水风险气候区划。结果表明：严寒地区和寒冷地区以低风险为主，占比分别为80.2%和95.3%，且均未出现高风险城镇；夏热冬冷、夏热冬暖和温和地区中风险占比最高，分别为68.2%、66.7%和59.1%，其中夏热冬暖地区尤为显著，高风险占比高达25%。这一发现强调了即使在热工设计标准一致的情况下，不同地区的建筑防水设计要求的差异也应得到充分考虑。
- 风驱雨 /
- 气候区划 /
- 建筑防水 /
- 建筑热工 /
- 建筑渗水
Abstract: Wind-driven rain is the main external factor causing rainwater infiltration in exterior walls，and there are significant differences in wind-driven rain climate conditions in various regions of China. This study proposes a method for assessing wind-driven rainwater infiltration climate risk that integrates building thermal design zoning，along with a set of corresponding indicators. The risk level of wind-driven rainwater infiltration in the main towns of existing building thermal design zoning was evaluated using these indicators，and a climate zone map for wind-driven rainwater infiltration risk in China was developed. The results show that the severe cold and cold regions are predominantly low-risk，accounting for 80. 2% and 95. 3%，respectively，with no highrisk towns observed in either region. In contrast，the hot summer and cold winter，hot summer and warm winter，and mild regions exhibit the highest proportions of medium-risk areas，at 68. 2%， 66. 7%，and 59. 1%，respectively. Among these，the hot summer and warm winter region is particularly significant，with a high-risk proportion reaching 25%. These findings emphasize that even if thermal design standards are consistent，differences in waterproofing design requirements for buildings in different regions should also be fully considered.
- wind-driven rain /
- climatic zoning /
- building waterproofing /
- building thermal design /
- infiltration

HTML全文

参考文献(15)

[1]	钱天达，张会波，陈超，等. 风驱雨对建筑外墙润湿的影响研究综述[J]. 建筑节能（中英文），2022，50（5）:1-9.
[2]	高延继，应群勇，邵高峰.《建筑外墙防水工程技术规程》解读[J]. 建设科技，2012，（19）:20-22.
[3]	中华人民共和国住房和城乡建设部. 建筑外墙防水防护技术规程:JGJ/T 235—2011[S]. 北京:中国建筑工业出版社，2011.
[4]	高延继，应群勇.《建筑外墙防水工程技术规程》JGJ/T 235— 2011阐释[C]//新防水堵漏工程标准宣贯与技术研讨会论文集. 北京:2011.
[5]	PU S，ZHANG H，FENG C，et al. Analyzing exposure risk and change characteristics of wind-driven rain in China under future climate scenarios[J]. Journal of Wind Engineering and Indus- trial Aerodynamics，2023，241:105544.
[6]	NIK V M ，MUNDT-PETERSEN S O ，KALAGASIDIS A S ，et al. Future moisture loads for building facades in Sweden:climate change and wind-driven rain[J]. Building & Environment， 2015，93:362-375.
[7]	穆海振. 上海地区风驱雨气候特征分析[J]. 西安建筑科技大学学报（自然科学版），2019，51（1）:128-133.
[8]	中华人民共和国住房和城乡建设部. 民用建筑热工设计规范:GB 50176—2016[S]. 北京:中国建筑工业出版社，2016.
[9]	SAUER P. An annual driven rain index for China[J]. Building and Environment，1987，22（4）:239-240.
[10]	QIAN T，ZHANG H. Assessment of long-term and extreme expo- sure to wind-driven rain for buildings in various regions of China[J]. Building and Environment，2021，189:107524.
[11]	SAHAL N，LACASSE M A. Experimental assessment of water penetration and entry into siding-clad wall specimen:No. IRCIR-862[R]. Ottawa:National Research Council of Canada，Insti- tute for Research in Construction，2004.
[12]	GIARMA C ，ARAVANTINOS D. On building components' exposure to driving rain in Greece[J]. Journal of Wind Engineer- ing & Industrial Aerodynamics，2014，125:133-145.
[13]	陈超，张会波，钱天达. 基于半经验模型的建筑风驱雨研究[J]. 建筑节能（中英文），2021，49（10）:95-102.
[14]	LACY R E ，SHELLARD H C. An index of driving rain[J]. Aus- tralian Meteorological Magazine，1962，91（1080）:177-184.
[15]	PEREZ-BELLA J M，DOMINGUEZ-HERNANDEZ J，RODRIGUEZSORIA B ，et al. Combined use of wind-driven rain and wind pressure to define water penetration risk into building façades:the spanish case[J]. Building and Environment，2013，64:46-56.
