半开式桁架桥主梁抗扭特性研究

岳子翔; 赵锐; 王立晓; 温庆杰

doi:10.3724/j.gyjzG23120504

半开式桁架桥主梁抗扭特性研究

doi: 10.3724/j.gyjzG23120504

岳子翔^1,2,
赵锐^1,2,
王立晓^1,2,
温庆杰³

1. 新疆大学建筑工程学院, 乌鲁木齐 830017;
2. 新疆建筑结构与抗震重点实验室, 乌鲁木齐 830017;
3. 中国矿业大学力学与土木工程学院, 江苏徐州 221116

基金项目:

江苏省研究生科研与实践创新计划项目（KYCX21_0116）；新疆维吾尔自治区自然科学基金项目（2024D01C250）。

详细信息

作者简介:
岳子翔，博士，副教授，主要从事桥梁工程方向研究。viscarialight@126.com

计量
- 文章访问数: 7
- HTML全文浏览量: 2
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2023-12-05
- 网络出版日期: 2026-01-06

Research on Torsional Characteristics of Main Girders in Half-Through Truss Bridges

1. College of Civil Engineering and Architecture, Xinjiang University, Urumqi 830047, China;
2. Xinjiang Key Laboratory of Building Structures and Earthquake Resistance, Urumqi 830017, China;
3. School of Mechanics and Civil Engineering, China University of Mining and Technology, Xuzhou 221116, China

摘要

摘要: 抗扭刚度对半开式桁架桥的稳定性与服役性能至关重要。为了研究半开式桁架桥主梁的抗扭特性从而增强桥梁性能，将半开式桁架桥的主梁等效为开口槽型薄壁构件。分析了半开式桁架桥主梁的扭转惯性矩计算式，并发现半开式桁架桥主桁通过抗弯来抵抗翘曲变形的效应，对主梁抗扭刚度贡献极大，进而基于主桁竖向抗弯作用提出了主梁的抗扭惯性矩修正值计算式。以一座半开式桁架人行桥为例，分别采取理论与有限元方法计算了不同宽跨比下桥梁的抗扭惯性矩。结果表明：计算半开式桁架桥主梁的抗扭惯性矩时，等效开口槽型截面计算所得自由扭转惯性矩与实际抗扭刚度差距极大，必须考虑主桁抗弯修正值。主桁抗弯协助抗扭的作用随宽跨比增大迅速提高，计入修正值后的理论解与有限元结果能够吻合，可以运用解析算式来探明此类桥梁的抗扭特性。根据机理分析，最终制定了在上横梁之间加装X形纵向支撑的方式提升抗扭刚度。加装X形纵向支撑不但能保持半开式桁架桥的尺寸不变且抗扭刚度的增强效果可观，还将对桥梁抗扭和稳定性能带来显著的改善效应。
- 半开式桁架桥 /
- 抗扭惯性矩 /
- 等效薄壁梁 /
- 刚度加强 /
- 理论研究
Abstract: Torsional stiffness is crucial for the stability and service performance of half-through truss bridges. To study the torsional characteristics of the main girder of a half-through truss bridge， the half-through truss is equated to an open-section thin-walled member， and the calculation formula for the free torsional moment of inertia of the main girder is derived. Since the main truss of the half-through truss bridge resists warping deformation through bending， it contributes significantly to the torsional stiffness of the main girder. Based on the vertical bending behavior of the main truss， the correction formula for the torsional moment of inertia of the main girder is derived. Taking a half-through truss pedestrian bridge as an example， the torsional moment of inertia of the bridge under different width-span ratios was calculated using theoretical and finite element analysis. The results showed that when calculating the torsional moment of inertia of the main girder of a half-through truss bridge， the free torsional moment of inertia calculated using the equivalent open-section differed significantly from the actual torsional stiffness， and the bending correction of the main truss must be considered. The contribution of the main truss to torsional resistance through bending increased rapidly with the increase in the width-span ratio. The theoretical solution， after incorporating the correction， showed good agreement with the finite element results. The theoretical formula can be used to explain the torsional mechanism of this type of bridge. However， since the theoretical calculation did not account for the beneficial effect of the transverse bending resistance of the bottom chord， the theoretical solution gradually became smaller than the finite element solution as the bridge width increased. Based on the mechanism study， a method of adding X-shaped longitudinal bracing between the upper transverse beams to improve the torsional stiffness was proposed. The addition of X-shaped longitudinal bracing not only preserves the dimensions of the half-through truss bridge but also significantly enhances the torsional stiffness and stability of the structure.
- half-through truss bridge /
- torsional moment of inertia /
- equivalent thin-walled beam /
- stiffness strengthening /
- theoretical research

HTML全文

参考文献(21)

[1]	WEN Q J，REN Z J. Structural analysis of a large aluminum alloy truss double-arch bridge[J]. Structures，2021，29（4）:924-936.
[2]	岳子翔，温庆杰，卓涛. 半开式桁架桥结构稳定性分析[J]. 工程力学，2018，35（增刊1）:270-277.
[3]	温庆杰，岳子翔，周牧，等. 半开式桁架桥上弦杆平面外屈曲临界力研究[J]. 华中科技大学学报（自然科学版），2018，46（1）:104-109.
[4]	李国豪. 桥梁与结构理论研究[M]. 上海:上海科学技术文献出版社，1983.
[5]	OKUMURA T，WATANABE H. An investigation of truss bridges under torsional loading[J]. Proceedings of the Institution of Civil Engineering，1965，121:1-9.
[6]	徐格宁. 空间桁架扭转惯性矩的计算[J]. 太原科技大学学报，1984（1）:46-57.
[7]	GILTNER B，KASSIMALI A. Equivalent beam method for trusses[J]. Practice Periodical on Structural Design& Construction，2000，5（2）:70-77.
[8]	周绪红，秦凤江，狄谨，等. 基于能量原理的板桁结合型加劲梁连续化分析方法[J]. 中国公路学报，2014，27（6）:34-43.
[9]	李永乐，王磊，向活跃，等. 板桁梁抗扭惯性矩的计算方法[J]. 工程力学，2018，35（3）:125-131.
[10]	ADAMAKOS T，VAYAS I，PETRIDIS S，et al. Modeling of curved composite I-girder bridges using spatial systems of beam elements[J]. Journal of Constructional Steel Research，2011，67（3）:462-470.
[11]	VIH C，CANDIDATE T A，ILIOPOULOS-ING A. Spatial systems for modelling steel‐concrete composite bridges:comparison of grillage systems and FE models[J]. Steel Construction，2010，3（2）:100-111.
[12]	SMYRNAIOS S V，ILIOPOULOS A，VAYAS I. Truss models for inelastic stability analysis and design of steel plate girders[J]. Engineering Structures，2015，105:165-173.
[13]	田村周平. 吊橋補剛トラスと床組鋼床板との合成構构造について（No.1）[J]. 橋梁，1974，10（3）:38-52.
[14]	XU Y L，KO J M，YU Z. Modal analysis of tower-cable system of tsing ma long suspension bridge[J]. Engineering Structures，1997，19（10）:857-867.
[15]	SIEKIERSKI W. Equivalent moment of inertia of a truss bridge with steel-concrete composite deck[J]. Structural Engineering& Mechanics，2015，55（4）:801-813.
[16]	熊波，罗锡林，谭惠丰. 全复合材料桁架扭转刚度分析[J]. 复合材料学报，2015，32（2）:501-507.
[17]	陈伯真. 薄壁结构力学[M]. 上海:上海交通大学出版社，1998.
[18]	严圣平. 材料力学[M]. 北京:科学出版社，2012.
[19]	WEN Q J，YUE Z X. Nonlinear stability of the upper chords in half-through truss bridges[J]. Steel and Composite Structures，2020，36（3）:307-319.
[20]	MURTHA-SMITH E. Cross stiffeners for beams in torsion[J]. Journal of Structural Engineering，1995，121（7）:1119-1124.
[21]	卞颖葛，郭耀杰，熊川，等. 考虑支座约束影响的大角钢轴压杆失稳形态研究[J]. 工业建筑，2021，51（3）:91-97.
