Analysis of Shear Mechanical Properties of Distributed Mortise-Tenon Joints in Super-Large Diameter Shield Tunnels
-
摘要: 分布式凹凸榫接头是大直径盾构隧道抵抗纵向环间剪切错台变形的新型接头形式。以芜湖城南超大直径过江隧道为原型,通过建立考虑局部塑性损伤影响的接头及管片抗剪力学数值模型,研究分布式凹凸榫接头的抗剪演化过程及其对隧道纵向传力的影响,并与连续式凹凸榫管片进行对比,最终通过理论计算模型验证了数值结果的可靠性。结果表明:1)在加载位移后,分布式凹凸榫接头剪力变化可分为Ⅰ~Ⅲ三个阶段,初始阶段接头不发挥抗剪作用,第II阶段从基本不提供抗剪力上升到占总抗剪力的64.4%,并在第Ⅲ阶段趋于平稳。2)分布式凹凸榫在受剪过程中,腰部以上凹凸榫抗剪力增长较快,贡献较大,在凹凸榫咬合阶段末其占总抗剪力的76%。3)分布式凹凸榫管片达到抗剪极限时的纵向应力松弛度λ为17.1%,而全环连续式凹凸榫管片应力松弛度λ为29.6%。前者的松弛区面积相对较小,这对隧道整体结构的纵向稳定控制及防渗漏具有积极意义。Abstract: The distributed mortise-tenon joint is a novel type of joint used in large-diameter shield tunneling to resist longitudinal shear dislocation deformation between adjacent rings. Using the Wuhu Chengnan Extra-Large Diameter River-Crossing Tunnel as a prototype, this study established a numerical model for the joint and segment shear behavior, incorporating the effects of local plastic damage. The research investigated the shear-resistance evolution of distributed mortise-tenon joints and their influence on longitudinal load transfer in the tunnel. A comparison was made with continuous mortise-tenon segments. Finally, the reliability of the numerical results was verified against a theoretical calculation model. The results showed that: 1) Under applied displacement, the shear force variation in distributed mortise-tenon joints exhibited three distinct stages (I-III). In Stage I, the joint contributed negligibly to shear resistance. In Stage II, the shear resistance increased sharply, reaching 64.4% of the total by the end of this stage. In Stage III, the shear force began to stabilize. 2) During shearing, the mortise-tenon joints above the waist experienced relatively rapid growth in shear resistance and contributed significantly, accounting for 76% of the total at the end of the engagement stage. 3) The longitudinal stress relaxation coefficient λ of the distributed mortise-tenon segment reached 17.1% at the ultimate shear limit, whereas that of the continuous ring-type mortise-tenon segment reached 29.6%. The relatively smaller relaxation area of the former is beneficial for controlling the longitudinal stability and preventing leakage of the overall tunnel structure.
-
Key words:
- shield tunnel /
- ring joint /
- distributed mortise-tenon joints /
- plastic damage /
- dislocation deformation
-
[1] 闫治国,彭益成,丁文其,等. 青草沙水源地原水工程输水隧道单层衬砌管片接头荷载试验研究[J]. 岩土工程学报,2011,33(9):1385-1390. [2] 朱瑶宏,张宸,柳献,等. 错缝拼装通用环管片环缝抗剪性能试验研究[J]. 铁道科学与工程学报,2017,14(2):315-324. [3] 柳献,李海涛,曹伟飚. 盾构隧道新型纵缝接头抗弯性能试验对比研究[J]. 现代隧道技术,2018,55(增刊2):1058-1068. [4] JIN Y,DING W,YAN Z,et,al. Experimental investigation of the nonlinear behavior of segmental joints in a water-conveyance tunnel[J]. Tunnelling and Underground Space Technology,2017,68:153-166. [5] 巩一凡,丁文其,龚琛杰,等. 大断面类矩形盾构隧道管片接头极限抗剪切承载力试验研究[J]. 土木工程学报,2019,52(11):120-128. [6] 桑运龙,刘学增,张强. 基于螺栓-凹凸榫连接的地铁盾构隧道管片环缝接头刚度分析及应用[J]. 隧道建设(中英文),2020,40(1):19-27. [7] 刘迅,封坤,肖明清,等. 盾构隧道新型分布榫式管片结构的局部原型试验研究[J]. 工程力学,2022,39(1):197-208. [8] 赵森森,张冬梅,黄忠凯. 大直径盾构隧道分布式凹凸榫受力特性[J]. 现代隧道技术,2022,59(5):54-62. [9] 秦浩,赵宪忠. ABAQUS混凝土损伤因子取值方法研究[J]. 结构工程师,2013,29(6):27-32. [10] 廖少明,门燕青,肖明清,等. 软土盾构法隧道纵向应力松弛规律的实测分析[J]. 岩土工程学报,2017,39(5):795-803. -
