Study on the Stability of Ultra-Small Radius Curved Beam Bracket System in Complex Soft Soil Foundation Environment of Fuli Expressway
-
摘要: 针对复杂软土地基环境下超小半径曲线梁支架系统施工的安全问题,以阜溧高速大纵湖互通C匝道桥工程为背景,采用有限元软件MIDAS/Civil建立支架系统模型,研究了复杂软土地基环境下曲线梁支架系统稳定性问题,分析了软土地基不均匀沉降、曲线梁曲率半径及支架跨度、宽度、高度等因素对支架系统力学性能的影响。结果表明:在软土地基不均匀沉降影响下,支架1和支架2失稳破坏时的水平杆最大应力分别为82.32,127.36 MPa,水平杆均未达到屈服状态,支架失稳由立杆自身刚度不足引起;在梁体混凝土达到一定强度时,支架屈曲荷载随着曲线梁曲率半径增大而增大,120 m曲率半径时,支架屈曲荷载比60 m曲率半径时增大了93%;支架宽度、高度对支架稳定性有较大影响,增大支架横向宽度和减小支架高度会提高支架稳定性,与支架宽度为16.5 m相比,宽度为22.5 m时支架屈曲荷载提高了62.34%。依据研究成果对支架系统进行沉降监控,现场监测显示,支架沉降监测数据均在规定范围内,表明软土地基环境下支架法施工有良好的可行性和安全性。Abstract: Aiming at the construction safety of ultra-small-radius curved beam bracket system under complex soft soil foundation environment, taking the Dazonghu Interchange C-ramp bridge project of Fuli Expressway as the background, the finite element software MIDAS/Civil was used to establish the bracket system model, the stability problem of curved beam bracket system under complex soft soil foundation environment was studied. The influence of uneven settlement of the soft soil foundation, curvature radius of the curved beam, and bracket span, width, and height on the stability of the bracket system was analyzed. The results show that under the influence of uneven settlement of the soft soil foundation, the maximum stresses of the horizontal rods when bracket 1 and 2 lose stability are 82.32 MPa and 127.36 MPa, respectively, and none of the horizontal rods reaches the yield state. The instability of the bracket is caused by the insufficient stiffness of the pole itself. When the concrete of the beam body reaches a certain strength, the buckling load of the bracket increases with the increase of the curvature radius of the curved beam, and the buckling load of the bracket of the 120 m curvature radius increases by 93% compared with that of the 60 m curvature radius. The width and height of the bracket have a great influence on the stability of the bracket. Increasing the lateral width of the bracket and reducing the height of the bracket will improve the stability of the bracket. Compared with the bracket width of 16.5 m, the buckling load of the bracket width of 22.5 m increases by 62.34%. Based on the research results, the sedimentation monitoring was conducted on the bracket system, and on-site monitoring showed that the bracket sedimentation monitoring data were within the specified range, indicating that the bracket method has good feasibility and safety for construction under soft foundation conditions.
-
[1] 黄峰,王莹,郝静,等. 基于监测数据的混凝土箱梁温度与应变多尺度相关性分析[J]. 科学技术与工程,2021,21(36):15624-15630. [2] 朱俊樸,李向阳. 60 m整体预制混凝土箱梁智慧建造技术研究[J]. 世界桥梁,2023,51(1):64-70. [3] 金恩,杨伟,王嘉祺. 预应力混凝土连续箱梁桥运维期开裂空间形态及机理分析[J]. 公路,2022,67(12):147-152. [4] 张运清,赵庆云,孟涛. 混凝土连续箱梁体外预应力加固技术研究[J]. 中外公路,2020,40(3):164-167. [5] 白应华,张佳,汤旭. 混凝土箱梁桥承重支架受力特性研究[J]. 工程抗震与加固改造,2021,43(4):167-171. [6] 桂志敬,张建东,冯晓楠,等. 承插型盘扣钢管支架在桥梁工程中的应用[J]. 公路交通科技,2018,35(10):76-81. [7] 任翔,黄杜康,宋飞,等. 满堂支架稳定性分析中的非线性因素研究[J]. 铁道建筑,2019,59(11):41-45. [8] 占玉林,许江辉,许俊,等. 基于响应面法和粒子群算法的桥梁高耸临时提升支架优化[J]. 中国铁道科学,2022,43(6):39-46. [9] 董春光,王晓佳,罗吉庆,等. 下横梁支架系统创新设计与施工[J]. 科学技术与工程,2022,22(22):9805-9811. [10] 徐嫚,李晓明,刘昌永,等. 地基冻胀条件下碗扣式模板支架稳定承载力分析[J]. 工业建筑,2022,52(1):108-115. [11] 潘博,刘爱林,王令侠. 芜湖长江三桥2号桥塔下横梁支架设计与施工[J]. 世界桥梁,2021,49(6):34-39. [12] 熊咸玉,戴俊. 大跨度现浇连续箱梁满堂支架结构稳定性分析及评价[J]. 西安科技大学学报,2020,40(2):268-274. [13] 刘苗,宁凯,孔令洲. 斜拉桥π形主梁组合式现浇支架结构设计研究[J]. 公路,2018,63(7):149-152. [14] 冉涛,李俊德,魏治国,等. 基于规模因素的高大满堂支架结构稳定性的研究[J]. 公路,2020,65(10):151-155. [15] 张晓光,吴永明. 支承于既有桥梁上的现浇箱梁支架体系设计研究[J]. 公路,2022,67(11):240-243. [16] 陈骥. 钢结构稳定理论与设计[M]. 5版. 北京:科学出版社,2011:533-535. [17] 中华人民共和国住房和城乡建设部. 建筑施工临时支撑结构技术规范:JGJ 300—2013[S]. 北京:中国建筑工业出版社,2013. -
