Research and Application on Pile-Soil Interaction Analysis and Optimized Design Method for Offshore Wind Power Large-Diameter Monopile Foundations
-
摘要: 单桩基础是被广泛使用的海上风电基础形式,中国海域的海床条件、严苛的环境荷载以及不断向深远海发展的进程使大直径长单桩更多地被应用在近海浅水地区的风电场。目前国内单桩基础设计主要采用p-y曲线法,该方法基于小直径柔性长桩试验得来,低估大直径单桩桩-土相互作用的刚度和承载力,增大了建造成本和施工难度。通过对比国外主流的单桩基础设计方法,建立了海上风电大直径单桩基础改进型桩-土相互作用分析优化设计方法。该关键技术基于挪威岩土所(NGI)提出的多弹簧分析模型,结合原位孔压静力触探(CPTU)试验以及高级土工试验的结果,可以更加精准地模拟桩-土相互作用效应,实现海上风电大直径单桩基础的精细化设计。Abstract: Monopile is a widely-used foundation form for offshore wind power. The seabed conditions in the sea area of Guangdong,harsh environment loads,and continuous development into deeper seas have lead to the wider application of large-diameter monopiles in offshore wind farms in shallow water area. At present,the monopile foundation design in China mainly adopts the p-y curve method. This method is based on the test of small-diameter long flexible piles,which underestimates the stiffness and bearing capacity of large-diameter monopile pile-soil interaction and increases construction costs and construction difficulties. By comparing the mainstream monopile foundation design methods in Europe,an improved pile-soil interaction analysis and optimized design method for large-diameter monopile foundations in offshore wind power has been established. The key technology is based on the multi-spring model proposed by NGI,combined with the results of in-situ CPTU tests and geotechnical tests,which can more accurately simulate the pile-soil interaction effect and achieve refined design of large-diameter monopile foundations for offshore wind power.
-
[1] 国家能源局. 海上风电场工程风电机组基础设计规范:NB/T 10105-2018[S]. 北京:中国水利水电出版社, 2018. [2] American Petroleum Institute. Recommended practice for plan-ning, designing and constructing fixed offshore platformsworking stress design:API RP 2A-WSD[S]. 21st Edition. Rockville:American Petroleum Institute, 2000. [3] MATLOCK H. Correlation for design of laterally loaded piles in soft clay[C]//American Society of Civil Engineers. Offshore Technology Conference. Houston, Texas:1970. [4] REESE L C, COX W R, KOOP F D. Field testing and analysis of laterally loaded piles in stiff clay[C]//American Society of Civil Engineers. Offshore Technology Conference. Houston, Texas:1975. [5] MCVAY M C, NIRAULA L. Development of p-y curves for large diameter piles/drilled shafts in limestone for fb-pier[R]. Gainesville:University of Florid, 2004. [6] Det Norske Veritas. Support structures for wind turbines. DNVGL standard:DNVGL-ST-0126[S]. Norway:Det Norske Veritas, 2018. [7] ZHANG Y, ANDERSEN K H. Scaling of lateral pile p-y response in clay from laboratory stress-strain curves[J]. Marine Structures, 2017, 53:124-135. [8] ZHANG Y, ANDERSEN K H. Soil reaction curves for monopiles in clay[J]. Marine Structures, 2019, 65:94-113. [9] FU D, ZHANG Y, AAMODT K K. A multi-spring model for monopile analysis in soft clays[J]. Marine Structures, 2010, 72: 102768. -
