单向加载下带楼板的可替换耗能连接K型偏心支撑钢框架极限承载力分析

殷占忠; 刘岸飞; 张宪栋

doi:10.3724/j.gyjzG22102303

单向加载下带楼板的可替换耗能连接K型偏心支撑钢框架极限承载力分析

doi: 10.3724/j.gyjzG22102303

1. 兰州理工大学土木工程学院, 兰州 730050;
2. 兰州理工大学西部土木工程防灾减灾教育部工程研究中心, 兰州 730050

基金项目:

国家自然科学基金项目（52568077，51968044）；甘肃省自然科学基金优秀博士生项目（25JRRA114）。

详细信息

作者简介:
殷占忠，博士，教授。yinzhanzhong@lut.edu.cn

计量
- 文章访问数: 14
- HTML全文浏览量: 3
- PDF下载量: 1
- 被引次数: 0
出版历程
- 收稿日期: 2022-10-23
- 网络出版日期: 2026-01-06

Analysis of Ultimate Bearing Capacity for K-Type Eccentrically Braced Steel Frames with Replaceable Energy-Dissipating Links and Floor Slabs Under Monotonic Loading

1. School of Civil Engineering, Lanzhou University of Technology, Lanzhou 730050, China;
2. Western Engineering Research Center of Disaster Mitigation in Civil Engineering of Ministry of Education, Lanzhou University of Technology, Lanzhou 730050, China

摘要

摘要: 近年来对K型偏心支撑钢框架的研究多是未考虑楼板的影响，将钢框架与楼板结合形成带组合梁的K型偏心支撑钢框架，推导在考虑楼板影响下带剪切型耗能连接的钢框架初始刚度、极限承载力算式。并利用ABAQUS软件建立17个模型分析其在单向荷载作用下的各项性能，结果表明：组合楼板可以提升钢框架的整体性能，改善水平力在结构中的传递，从而大幅度提高结构的各项抗震性能。基于楼板作用下带剪切型耗能连接K型偏心支撑钢框架所推导算式的计算结果，与ABAQUS模拟结果相比，误差基本都在15%以内，具有较好的吻合，为后续带楼板的剪切型耗能连接K型偏心支撑钢框架的承载力与刚度计算分析提供一些算式参考。
- 可替换耗能连接 /
- 楼板 /
- 偏心支撑 /
- 初始刚度 /
- 极限承载力
Abstract: In recent years， research on K-type eccentrically braced steel frames has often neglected the influence of floor slabs. By integrating a steel frame with floor slabs to form a K-type eccentrically braced steel frame with composite beams， this study derived formulas for the initial stiffness and ultimate bearing capacity of the steel frames with shear links under the influence of floor slabs. Additionally， the ABAQRS software was used to establish 17 models to analyze its performance under unidirectional loading. The results showed that the combination of floor slabs improved the overall performance of the steel frame and enhanced the transmission of horizontal forces in the structure， thereby significantly improving its seismic performance. The calculation results based on the deduced formula for the K-type eccentrically braced steel frame with shear links under floor slab action were compared with the ABAQUS simulation results. The error of the derived formula was found to be within 15%， showing good agreement. This provides some formula references for calculating and analyzing the bearing capacity and stiffness of K-type eccentrically braced steel frames with shear links and floor slabs.
- replaceable energy-dissipating link /
- floor slab /
- eccentrically braced /
- initial stiffness /
- ultimate bearing capacity

HTML全文

参考文献(16)

[1]	FUJIMOTO M，AOYAGI T，UKAI K，et al. Structural characteristics of eccentric k-braced frames[J]. Transactions AIJ，1972，195（5）:39-49.
[2]	TANABASHI R，NANETA K，ISHIDA T. On the rigidity and ductility of steel bracing assemblage[C]// Proceedings of the 5th World Conference on Earthquake Engineering. IAEE Rome:1974:834-840.
[3]	LIBBY J R. Eccentrically braced frame construction-a case study[J]. Engineering Journal，AISC，1981，18（4）:149-153.
[4]	OKAZAKI T，ARCE G，RYU H C，et al. Experimental study of local buckling，overstrength，and fracture of links in eccentrically braced frames[J]. Journal of Structural Engineering，2005，131（10）:1526-1535.
[5]	OKAZAKI T，ENGELHARDT M D，NAKASHIMA M，et al. Experimental performance of link-to-column connections in eccentrically braced frames[J]. Journal of Structural engineering，2006，132（8）:1201-1211.
[6]	MANSOUR N，SHEN Y，CHRISTOPOULOS C，et al. Experimental evaluation of nonlinear replaceable links in eccentrically braced frames and moment resisting frames[C]// The 14th World Conference on Earthquake Engineering. Beijing，China:2008.
[7]	石永久，熊俊，王元清，等. 多层钢框架偏心支撑的抗震性能试验研究[J]. 建筑结构学报，2010，31（2）:29-34.
[8]	段留省，苏明周，郝麒麟，等. 高强钢组合K形偏心支撑钢框架抗震性能试验研究[J]. 建筑结构学报，2014，35（7）:18-25.
[9]	李腾飞，苏明周，郭江然. 基于多目标性能的高强钢组合K形偏心支撑框架塑性设计方法研究[J]. 建筑结构学报，2023，44（1）:10-22.
[10]	殷占忠，何玉龙，冯大哲，等. 单向加载下带腹板连接型可替换连接件的K形偏心支撑钢框架参数分析[J]. 兰州大学学报（自然科学版），2021，57（6）:815-822.
[11]	YIN Z Z，YANG B，ZHANG X B. Design of an eccentrically buckling-restrained braced steel frame with web-bolted replaceable links[J]. Journal of Constructional Steel Research，2022，192，107250.
[12]	中华人民共和国住房和城乡建设部. 钢结构设计标准:GB 50017—2017[S]. 北京:中国建筑工业出版社，2018.
[13]	苏明周，李慎，连鸣，等. K形偏心支撑钢框架的弹性抗侧刚度与极限承载力[J]. 西安建筑科技大学学报（自然科学版），2014，46（6）:791-799.
[14]	ENGLEKIRK R E. Steel structures:controlling behavior through design[M]. New York:1994.
[15]	陈绍蕃. 钢结构设计原理[M]. 4版. 北京:科学出版社，2016.
[16]	王彦栋. 带RC楼板的可更换钢连梁抗震性能及设计方法研究[D]. 北京:清华大学，2016.
