波纹钢板覆面冷弯型钢剪力墙抗剪承载力计算公式

刘希宇; 林建萍; 张文莹; 余少乐

doi:10.3724/j.gyjzG22061010

波纹钢板覆面冷弯型钢剪力墙抗剪承载力计算公式

doi: 10.3724/j.gyjzG22061010

1. 北京工业大学, 工程抗震与结构诊治北京市重点试验室, 北京 100124;
2. 上海天华建筑设计有限公司, 上海 200235;
3. 中国建筑第八工程局有限公司, 上海 200135

基金项目:

国家自然科学基金项目（52008008）；北京市教委项目（KM202010005029）；上海市青年科技启明星计划（21QB1406400）。

详细信息

作者简介:
刘希宇，硕士研究生。

通讯作者:
张文莹，博士，副教授，主要从事钢结构及抗震性能方面的研究，wenyingchangan@163.com。

计量
- 文章访问数: 21
- HTML全文浏览量: 6
- PDF下载量: 1
- 被引次数: 0
出版历程
- 收稿日期: 2022-06-10
- 网络出版日期: 2026-04-11
- 刊出日期: 2026-03-20

Calculation Method for the Shear Capacity of Corrugated Steel Sheet-Sheathed Cold-Formed Steel Shear Walls

1. Beijing Key Laboratory of Earthquake Engineering and Structural Retrofit, Beijing University of Technology, Beijing 100124, China;
2. Shanghai Tianhua Architecture Planning & Engineering Co., Ltd., Shanghai 200235, China;
3. China Construction Eighth Engineering Division Co., Ltd., Shanghai 200135, China

摘要

摘要: 波纹钢板覆面冷弯型钢剪力墙是一种新型的侧向力抵抗体系，凭借高抗剪承载力、不可燃性等特点，近年来受到广泛关注。目前该类墙体的抗剪承载力主要通过试验方法确定，面板形式单一且缺乏理论依据。为此，针对波纹钢板剪切屈曲的理想破坏模式建立波纹钢板覆面墙体抗剪承载力理论计算方法，将墙体抗剪承载力通过面板的抗剪承载力进行近似替代，通过建立220组波纹钢板剪切屈曲荷载的有限元模型，对其进行计算及特征值屈曲分析，综合考虑波纹钢板的剪切屈曲强度和屈曲后强度，提出波纹钢板覆面墙体抗剪承载力的计算方法。该方法形式简单，计算准确度较高，可以对肋高15 mm左右的波纹钢板覆面墙体抗剪承载力进行预测。
- 冷弯型钢剪力墙 /
- 波纹钢板 /
- 抗剪承载力 /
- 设计方法 /
- 屈曲分析
Abstract: Corrugated steel sheet-sheathed cold-formed steel （CFS） shear walls are a new type of lateral force-resisting system. They have attracted extensive attention in recent years due to their high shear capacity and non-flammability. At present the shear capacity of such shear walls is mainly determined through experiments. There is limited variety in sheathing profiles and a lack of theoretical basis. To establish a design method for the shear capacity of corrugated steel sheet-sheathed shear walls， the shear capacity of shear walls was approximated by that of the sheathing instead. A total of 220 finite element models were developed to investigate the shear buckling load of corrugated steel sheets， and an eigenvalue buckling analysis was conducted. By considering both the elastic buckling strength and post-buckling strength of corrugated steel sheets， a calculation method for the shear capacity of corrugated steel sheet-sheathed shear walls was established. This method features a simple formulation and high computational accuracy， providing effective predictions for the shear capacity of walls sheathed with corrugated sheets having a rib height of approximately 15 mm.
- CFS shear wall /
- corrugated steel sheet /
- shear capacity /
- design method /
- buckling analysis

HTML全文

参考文献(27)

[1]	SERRETTE R L，HALL G，NGUYEN H. Additional shear wall values for light weight steel framing[R]. Washington，D C:American Iron and Steel Institute，1997.
[2]	YU C. Shear resistance of cold-formed steel framed shear walls with 0.686 mm，0.762 mm，and 0.838 mm steel sheet sheathing[J]. Engineering Structures，2010，32（6）:1522-1529.
[3]	YU C，CHEN Y. Detailing recommendations for 1.83 m wide cold-formed steel shear walls with steel sheathing[J]. Journal of Constructional Steel Research，2011，67（1）:93-101.
[4]	贾蓬春，闫维明，虞诚. 考虑重力荷载的冷弯薄壁型钢组合墙抗震性能研究[J]. 工业建筑，2017，47（5）:137-143.
[5]	中华人民共和国住房和城乡建设部. 低层冷弯薄壁型钢房屋建筑技术规程:JGJ 227—2011[S]. 北京:中国建筑工业出版社，2011.
[6]	中华人民共和国住房和城乡建设部. 冷弯薄壁型钢多层住宅技术标准:JGJ/T 421—2018[S]. 北京:中国建筑工业出版社，2018.
[7]	American Iron and Steel Institute（AISI）. North American standard for cold-formed steel structural framing:AISI S240-15[S]. Washington，D.C.:AISI，2015.
[8]	American Iron and Steel Institute（AISI）. North American standard for seismic design of cold-formed steel structural systems:AISI S400-15[S]. Washington，D.C.:AISI，2015.
[9]	张文莹. 波纹钢板覆面冷弯薄壁型钢龙骨式复合墙体抗震性能研究[D]. 上海:同济大学，2018.
[10]	刘飞. 冷弯薄壁型钢低层住宅结构体系的抗震性能研究[D]. 上海:同济大学，2010.
[11]	郭鹏，何保康，周天华，等. 冷弯型钢骨架墙体受剪承载力计算方法研究[J]. 建筑结构学报，2010，31（1）:9-15.
[12]	中华人民共和国建设部. 冷弯薄壁型钢结构技术规范:GB 50018—2002[S]. 北京:中国计划出版社，2002.
[13]	American Iron and Steel Institute（AISI）. North American specification for the design of cold-formed steel structural members:AISI S100-07[S]. Washington，D.C.:AISI，2007.
[14]	TONG J Z，GUO Y L. Elastic buckling behavior of steel trapezoidal corrugated shear walls with vertical stiffeners[J]. Thin-Walled Structures，2015，95:31-39.
[15]	EASLEY J T，MCFARLAND D E. Buckling of light-gage corrugated metal shear diaphragms[J]. Journal of the Structural Division，1969，95（ST 7）:1497-1516.
[16]	EASLEY J T. Buckling formulas for corrugated metal shear diaphragms[J]. Journal of the Structural Division，1975，101（ST 7）:1403-1417.
[17]	ELGAALY M，CACCESE V，DU C. Postbuckling behavior of steel-plate shear walls under cyclic loads[J]. Journal of Structural Engineering，1993，119（2）:588-605.
[18]	聂建国，唐亮. 基于弹性扭转约束边界的波形钢板整体剪切屈曲分析[J]. 工程力学，2008，25（3）:1-7.
[19]	DOU C，JIANG Z Q，PI Y L，et al. Elastic shear buckling of sinusoidally corrugated steel plate shear wall[J]. Engineering Structures，2016，121:136-146.
[20]	WANG S，ZHANG Y，LUO T，et al. Elastic critical shear buckling stress of large-scale corrugated steel web used in bridge girders[J]. Engineering Structures，2021，244:112757.
[21]	SCHAFER B W，PEKÖZ T. Direct strength prediction of cold-formed steel members using numerical elastic buckling solutions[C]// Proceedings of the 14th International Specialty Conference on Cold-Formed Steel Structures. St. Louis:University of Missouri-Rolla，1998:1-11.
[22]	YU C，YU G. Experimental investigation of cold-formed steel framed shear wall using corrugated steel sheathing with circular holes[J]. Journal of Structural Engineering，2016，142（12）:04016126.
[23]	YU C，HUANG Z，VORA H D，et al. Cold-formed steel framed shear wall assemblies with corrugated sheet steel sheathing[C]// Proceedings of the Annual Stability Conference Structural Stability Research Council. Phoenix:Structural Stability Research Council，2009:257-276.
[24]	MAHDAVIAN M. Innovative cold-formed steel shear walls with corrugated steel sheathing[D]. Denton:University of North Texas，2016.
[25]	刘希宇，赵岩，李易，等. 不同波形的波纹钢板覆面冷弯型钢剪力墙有限元研究[J]. 建筑钢结构进展，2021，23（7）:31-41.
[26]	刘希宇. 波纹钢板覆面冷弯型钢剪力墙抗剪性能研究[D]. 北京:北京工业大学，2022.
[27]	YI J，GIL H，YOUM K，et al. Interactive shear buckling behavior of trapezoidally corrugated steel webs[J]. Engineering Structures，2008，30（6）:1659-1666.
