不同热处理条件下NiTi形状记忆合金棒力学性能试验研究及有限元分析

袁振

doi:10.3724/j.gyjzG24101101

不同热处理条件下NiTi形状记忆合金棒力学性能试验研究及有限元分析

doi: 10.3724/j.gyjzG24101101

袁振

中铁长安重工有限公司, 西安 710032

基金项目:

国家自然科学基金项目（52008330451）。

详细信息

作者简介:
袁振，工学博士，工程师，主要从事钢结构及仿古建筑研究。电子信箱:sdzheny@163.com

计量
- 文章访问数: 37
- HTML全文浏览量: 7
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2024-10-11
- 网络出版日期: 2025-06-07
- 刊出日期: 2025-04-01

Experimental Investigation and Finite Element Analysis of the Mechanical Properties of NiTi Shape Memory Alloy Bars Under Diverse Heat Treatment Conditions

YUAN Zhen

China Railway Chang'an Heavy Industry Co., Ltd., Xi'an 710032, China

摘要

摘要: 为提高大直径NiTi 形状记忆合金（SMA）棒的力学性能，设计了6组不同热处理条件下的SMA棒进行恒定增量应变循环加载，得到SMA棒的应力-应变曲线、累积耗能量、残余变形及割线刚度等力学性能指标，提出了SMA棒本构模型。结果表明：随着热处理温度的增加，SMA棒的残余应变及最大应变均增大；在相同加载位移下，热处理温度越低，SMA棒应变量越高；当热处理温度一定时，随着加热时间的增长，SMA残余变形逐渐增大。当热处理温度为400 ℃、加热时长为15 min时，SMA棒的力学性能最佳。此外，将SMA棒应用到带摩擦阻尼器的钢结构梁柱节点进行有限元分析，结果表明：附设SMA-摩擦阻尼器的钢结构梁柱节点模型的滞回曲线呈现出良好的“捏缩”效应，残余变形显著减小，表现出良好的可恢复功能。
- NiTi 形状记忆合金（SMA） /
- 热处理 /
- 力学性能 /
- 本构模型 /
- 有限元分析
Abstract: To improve the mechanical properties of large-diameter NiTi shape memory alloy （SMA） bars， six groups of SMA bars under different heat treatment conditions were designed for constant incremental strain cyclic loading. The stress-strain curves， cumulative energy consumption， residual deformation， secant stiffness， and other mechanical property indicators of the SMA bars were obtained， and a constitutive model of the SMA bars was proposed. The results showed that with the increase of heat treatment temperature， both the residual strain and maximum strain of the SMA bars increased. Under the same loading displacement， the lower the heat treatment temperature， the higher the strain of the SMA bars. When the heat treatment temperature was constant， with the increase of heating time， the residual deformation of SMA gradually increased. When the heat treatment temperature reached 400 °C and the heating time reached 15 minutes， the mechanical properties of the SMA bars were optimal. Furthermore， finite element analysis was conducted on a steel beam-column joint equipped with a friction damper using SMA. The results showed that the hysteretic curves of the steel beam-column joint model equipped with the SMA-friction damper exhibited a significant "pinching" effect， leading to a notable reduction in residual deformation and demonstrating excellent recoverable functionality.
- NiTi shape memory alloy （SMA） /
- heat treatment /
- mechanical properties /
- constitutive model /
- finite element analysis

HTML全文

参考文献(21)

[1]	朱雪洁，钟诗江，杨晓霞，等. NiTi基形状记忆合金弹热效应及其应用研究进展［J］. 材料工程，2021，49（3）:1-13.
[2]	REZAEI S，SALMANI A. Shape memory alloys effects on the multi-story structures under extreme loading conditions［J］. Structures，2023，29（58），105660.
[3]	吕志林，姜旭，强旭红，等. 基于自应力形状记忆合金加固损伤钢结构的可行性研究［J］. 工业建筑，2022，52（6）:174-182.
[4]	CLADERA A，WEBER B，LEINENBACH C，et al. Iron-based shape memory alloys for civil engineering structures:an overview［J］. Construction and Building Materials，2014，63:281-293.
[5]	SASMAZ M，CHERNENK V A，MARTINEZ E，et al. Structure and magnetic-field induced effects in Mn-Ni（Fe）-Sn metamagnetic shape memory alloys［J/OL］. Materials Today:Proceedings，2015［ 2015-12-31］. https://doi.10.1016/j.matpr.2015.07.415.
[6]	YILDIZ K. Influence of aging on transformation characteristic and phase structure of a Cu-12.4 Al-1.2 Ti-1.2 Ta shape memory alloy［J］. Applied Physics A，2020，126（6）:422-429.
[7]	俞昊然，李维滨. NiTi形状记忆合金棒材的循环拉伸试验及力学性能退化分析［J/OL］. 工业建筑，2025［ 2025-02-24］. http://kns.cnki.net/kcms/detail/11.2068.TU.20230228.1839.006.html.
[8]	PUOPOLO R，RUSCHENDORF S，THADAYIL S A，et al. The effect of cobalt alloying on the phase transformation kinetics of Ni-Ti alloys［J］. Heliyon，2024，10（18）:37390..
[9]	AZUBUIKE A，MYSARA M，SYAHRIR R，et al. Advancing engineering frontiers with NiTi shape memory alloys:a multifaceted review of properties，fabrication，and application potentials［J］. Journal of Alloys and Compounds，2024，976（1），173227.
[10]	周玉浩，连鸣，王颜凯，等. 7×19构型NiTi形状记忆合金绞线超弹性试验研究［J］. 材料导报，2024，38 （21）:242-251.
[11]	雷波. CuAlNi形状记忆合金复合材料制备及性能研究［D］. 延安:延安大学，2023.
[12]	惠迎新，薛彦杰，王文炜，等. FRP/形状记忆合金复合材料力学性能和可回复性能试验研究［J］. 复合材料学报，2023，40（9）:5302-5314.
[13]	王亮迪，许英杰，王骏，等. 形状记忆合金增强复合材料力学试验分析［J］. 航空兵器，2023，30（2）:70-76.
[14]	ZHOU Y，LIAN M，WANG Y，et al. Cyclic and uniaxial tensile properties of superelastic niti shape memory alloy cables［J］. Smart Materials and Structures，2024，33（6），065005.
[15]	NING Q J，ZHU L H，HAN W，et al. Experimental study on mechanical properties of large NiTi superelastic shape memory alloy bars［J］. Smart Materials and Structures，2021，31（1），015024.
[16]	LEE W J，WEBER B，FELTRIN G，et al. Stress recovery behaviour of an Fe–Mn–Si–Cr–Ni–VC shape memory alloy used for prestressing［J］. Smart Materials and Structures，2013，22（12），125037.
[17]	IASNII V，YASNIY O，HOMON S，et al. Capabilities of self-centering damping device based on pseudoelastic NiTi wires［J］. Engineering Structures，2023，278，115556.
[18]	邱灿星，刘家旺，杜修力. SMA 滑动摩擦阻尼器的数值模拟及参数分析［J］. 工程力学，2022，39（8）:69-79.
[19]	QIU C Q，LIU J W，JIANG T Y，et al. Tests of double-stage SMA slip friction damper［J］. Engineering Structures，2023，288，116171.
[20]	国家标准化管理委员会. 超弹性钛镍形状记忆合金棒材和丝材:GB/T 39989—2021［S］. 北京:中国标准出版社，2021.
[21]	国家标准化管理委员会. 金属材料拉伸试验第1部分:室温试验方法:GB/T 228.1—2021 ［S］. 北京:中国标准出版社，2021.
