Experimental Research on Flexural Performance of Integral Grilles for New-Type Grille Composite Formworks
-
摘要: 新型格栅组合模架由整体式铝合金格栅、塑料模板及可调支撑等组成。以该组合模架中的整体式铝合金格栅为对象,对其在竖向均布荷载作用下的受弯性能进行了试验研究与有限元分析。结果表明:格栅受弯的变形与应力试验数据及有限元计算结果基本吻合,以此确定了该格栅的应用范围,即适用于厚度在350 mm以内的混凝土楼板支模施工,其最大承受荷载为8.79 kN/m2,且由次楞刚度控制。在此基础上,根据格栅受力特点,提出了便于应用且安全可行的简化计算方法,该方法可快捷评估格栅的受力状态。Abstract: The new-type grille composite formwork is composed of integral aluminum alloy grilles, plastic templates and adjustable supports. Taking the integral aluminum alloy grille as the object, experimental study and finite element analysis of its flexural performance were carried out under vertical uniformly distributed loads. The results showed that the bending deformation and stress test data of the grille were basically consistent with the finite element calculation results, so the application scope of the grille was determined, that is, it would be suitable for the formwork construction of the concrete floor with thickness less than 350 mm. Its maximum bearing load was 8.79 kN/m2, which was controlled by the secondary ridge stiffness. On this basis, according to the force characteristics of the grille, a simplified calculation method, which is easy to apply, safe and feasible, was proposed. This method could quickly evaluate the force state of the grille.
-
Key words:
- grille /
- mechanical properties /
- experiment /
- simplified method
-
[1] 张仲华,孙晖,陈炬,等. 新型格栅模架体系研究与应用[J]. 住宅与房地产,2019(36):88- 89. [2] 石开荣,林金龙,许洁槟,等. 新型阵列式组合模架足尺稳定性试验及有限元分析[J]. 工业建筑,2020,50(3):142- 146. [3] 石开荣,卢永徽,林金龙,等. 改进型阵列式组合模架体系整体稳定性研究[J]. 施工技术(中英文),2021,50(21):83- 88. [4] 王宜彬. 新型模板力学性能试验研究[D]. 西安:西安建筑科技大学,2020. [5] 杨旭. 铝合金模板的力学计算模型研究及工程应用[D]. 大连:大连理工大学,2020. [6] 严姣. 铝合金模板体系的力学性能及风振响应分析[D]. 广州:华南理工大学,2015. [7] SHI K R,XU J B,JIANG Z R,et al. Mechanical properties of new composite wood-plastic formworks with aluminum alloy frame[J]. Advances in Civil Engineering,2020(12):1- 19. [8] 潘钦锋,崔洪亨,蔡雪峰,等. 铝合金模板抗弯性能试验研究及参数分析[J]. 工业建筑,2017,47(11):142- 147. [9] 中华人民共和国住房和城乡建设部. 组合铝合金模板工程技术规程:JGJ 386—2016[S]. 北京:中国建筑工业出版社,2016. [10] 中华人民共和国住房和城乡建设部. 建筑施工模板安全技术规范:JGJ 162—2008[S]. 北京:中国建筑工业出版社,2008. 期刊类型引用(2)
