钢结构梁柱半刚性连接性能数值分析研究

夏心红; 方辉; 舒兴平; 邹岱珒; 李鹏; 毛健宇; 朱政; 何益斌

doi:10.3724/j.gyjzG23070607

钢结构梁柱半刚性连接性能数值分析研究

doi: 10.3724/j.gyjzG23070607

1. 湖南省建筑设计院集团股份有限公司, 长沙 410012;
2. 湖南大学土木工程学院, 长沙 410082

基金项目:

湖南省建筑设计院集团股份有限公司科技研发课题(KY03-0000-2023-0071)。

详细信息

作者简介:
夏心红,博士,研究员级高级工程师,主要从事复杂结构设计工作。

通讯作者:
方辉,fangh@hnadi.com.cn。

计量
- 文章访问数: 19
- HTML全文浏览量: 4
- PDF下载量: 2
- 被引次数: 0
出版历程
- 收稿日期: 2023-07-06
- 网络出版日期: 2025-04-02

Numerical Analysis of Semi-Rigid Beam-Column Connections in Steel Structures

1. Hunan Architectural Design Institute Group Co., Ltd., Changsha 410012, China;
2. College of Civil Engineering, Hunan University, Changsha 410082, China

摘要

摘要: 为探讨钢结构梁柱半刚性节点三参数幂函数弯矩-转角曲线形状系数的精准性,采用有限元软件ANSYS对其进行仿真分析。针对外伸端板半刚性连接典型节点,分别建立了有限元实体模型和组件法的三参数幂函数模型,与试验结果进行验证,并通过有限元实体模型和组件法-三参数幂函数模型,基于韦伯分布,拟合了外伸端板半刚性连接形状系数的实用计算公式。结果表明:基于韦伯分布建立的外伸端板半刚性连接节点的形状系数计算公式,与已有计算公式比较,具有更高的精度;通过赋予Combin 39单元由组件法-三参数幂函数获得的弯矩-转角曲线建立有限元简化模型来进行设计,不仅能较为精准地模拟节点的性能,而且相对于有限元实体模型更为简便,便于在实际工程中应用,为设计钢结构梁柱非线性半刚性节点提供可靠的参考和依据。
- 钢结构 /
- 半刚性连接 /
- 非线性 /
- 有限元分析 /
- 形状系数
Abstract: In order to discuss the accuracy of the shape factor of the three-parameter power function moment-rotation curves of semi-rigid steel beam-column joints, the finite element software ANSYS was used to simulate and analyze. The finite element solid model and the three-parameter power function model based on the component method were established respectively for the typical semi-rigid joints of the extended end plate, which were verified with the test results. Based on the Weber distribution, the practical calculation formula of the shape factor of the semi-rigid connection of the extended end plate was fitted through the finite element solid model and the three-parameter power function model based on the component method. The results showed that the formula for calculating the shape factor of semi-rigid connections with extended end plates based on Weber distribution was more accurate than the existing formula; by giving COMBIN39 element a simplified finite element model of bending moment-rotation curves obtained from the three parameter power function based on the comporent method, the design could not only accurately simulate the mechanical properties of the joint, but also could be simpler than the finite element solid model, which is convenient for application in practical projects, and provided a reliable reference and basis for the design of nonlinear semi-rigid joints of steel structure beams and columns.
- steel structure /
- semi-rigid connection /
- nonlinear /
- finite element analysis /
- shape factor

HTML全文

参考文献(15)

[1]	王燕,李华军,厉见芬.半刚性梁柱节点连接的初始刚度和结构内力分析[J].工程力学,2003(6):65-69.
[2]	范昕,李国强,孙飞飞.波纹腹板H型钢梁柱端板螺栓连接节点抗弯性能[J].同济大学学报(自然科学版),2014,42(7):1017-1023.
[3]	李国强,段炼,陆烨,等.H型钢梁与矩形钢管柱外伸式端板单向螺栓连接节点承载力试验与理论研究[J].建筑结构学报,2015,36(9):91-100.
[4]	李国强,段炼,陆烨,等.H型钢梁与矩形钢管柱端板单向螺栓连接节点初始转动刚度性能[J].同济大学学报(自然科学版),2018,46(5):565-573.
[5]	THAI H T,UY B. Finite element modelling of blind bolted composite joints[J]. Journal of Constructional Steel Research,2018,148:383-398.
[6]	张婧,胡夏闽,杜浩,等.钢-混凝土组合节点平齐式端板连接抗震性能试验研究[J].建筑结构学报,2019,40(增刊):109-117.
[7]	门进杰,王家琛,樊冠磊,等.RCS梁柱节点半刚性连接弯矩-转角关系模型研究[J].土木工程学报,2020,53(10):36-50.
[8]	覃健桂,潘建荣,王湛,等.考虑空间构造的T型件连接节点抗震性能研究[J].中南大学学报(自然科学版),2021,52(11):3958-3969.
[9]	赵均海,樊军超,高伟琪.钢管混凝土柱-钢梁延伸式端板连接节点初始转动刚度计算模型[J].建筑结构学报,2021,42(2):103-111.
[10]	European Committee for Standardization.Eurocode3,design of steel structures,part 1.8:design of joints: EN 1993-1-8[S].London: British Standards Institution, 2003.
[11]	中国工程建设标准化协会.端板式半刚性连接钢结构技术规程:CECS 260∶2009[S].北京:中国计划出版社,2009.
[12]	中华人民共和国住房和城乡建设部.钢结构设计标准:GB 50017—2017[S].北京:中国建筑工业出版社,2018.
[13]	施刚. 钢框架半刚性端板连接的静力和抗震性能研究[D].北京:清华大学,2005.
[14]	COLSON A. Connections incidence on the inelastic behavior of steel structures[C]// Euromech Colloquium 174.1983.
[15]	刘伟. 半刚性连接钢框架设计理论与方法[D].南京:东南大学,2016.
