碳纤维复合材料板拉伸性能影响因素试验研究

李彪; 赵娜; 赵进阶; 杨勇新; 田密; 刘欣媛

doi:10.13204/j.gyjzG23040405

碳纤维复合材料板拉伸性能影响因素试验研究

doi: 10.13204/j.gyjzG23040405

1. 中冶建筑研究总院有限公司, 北京 100088;
2. 西安建筑科技大学土木工程学院, 西安 710055

基金项目:

国家重点研发计划项目（2017YFC0703000）。

详细信息

作者简介:
李彪,男,1986年出生,高级工程师。电子信箱:no_1libiao@163.com

计量
- 文章访问数: 350
- HTML全文浏览量: 20
- PDF下载量: 2
- 被引次数: 0
出版历程
- 收稿日期: 2023-04-04
- 网络出版日期: 2023-12-18

Experimental Research on Influencing Factors of Tensile Properties of CFRP Plates

1. Central Research Institute of Building and Construction Co., Ltd., MCC Group, Beijing 100088, China;
2. School of Civil Engineering, Xi'an University of Architecture & Technology, Xi'an 710055, China

摘要

摘要: 为了改善碳纤维复合材料板的锚固性能，同时为了提高碳纤维复合材料板的拉伸性能，通过静载试验研究了碳纤维复合材料板的破坏现象、锚固树脂的种类、基体树脂的种类、纤维体积含量对拉伸性能的影响。结果表明：爆炸式破坏是最合理的破坏模式，最能反映碳纤维复合材料板的拉伸性能，拉伸强度大于脆性断裂的强度；锚固树脂剪切强度越大，越利于锚固，建议采用环氧胶膜进行锚固；基体树脂的黏性，对拉伸性能影响较大；对于1.2 mm的碳纤维板，随着纤维体积含量的增加，拉伸强度先增加后降低，弹性模量逐步增加，本次最优配合比为66%。
- 碳纤维复合材料板 /
- 锚固效率 /
- 基体树脂 /
- 纤维体积含量
Abstract: In order to improve the anchoring performance and tensile properties of carbon fibre reinforced plastics (CFRP) plates, the influence of failure phenomenon, types of anchoring resin, types of matrix resin, and fiber volume content on the tensile properties of carbon fiber plates were studied by static load test. The results showed that explosive failure was the most reasonable failure mode, which could best reflect the real performance of CFRP plates, and the tensile strength was greater than that of brittle fracture. The greater the shear strength of the anchoring resin, the more conducive to anchoring, and it was recommended to use epoxy film for anchoring; the viscosity of the matrix resin had a great influence on the tensile properties; for 1.2 mm CFRP plates, with the increase of fiber volume content, the tensile strength first increased and then decreased, and the elastic modulus gradually increased, and the optimal fit ratio was 66%.
- CFRP plates /
- anchoring efficiency /
- matrix resin /
- fiber volume content

HTML全文

参考文献(11)

[1]	NANNI A, SAADATMANESH H, EHSANI M R, et al. State of the art report on fiber reinforced plastic (FRP) reinforcement for concrete structures[J]. ACI Structural Journal, 1996:440R-1.
[2]	张锦涛.预应力碳纤维板锚具有限元分析与试验研究[D]:重庆:重庆大学,2014.
[3]	MEIER U. Brückensanierungen mit Hochleistungs-Faserverbund werkstoffen[J]. Material und Technik, 1987, 15(4):125-128.
[4]	DEURING M.Strengthening of reinforced concrete using prestressed FRP[R].German:EMPa Dübendorf,1993:279.
[5]	QUANTRILL R J,HOLLAWAY L C.The flexural rehabilitation of reinforced concrete beams by the use of prestressed advanced composite plates[J].Composites Science and Technology,1998(58):1259-1279.
[6]	WIGHT R G,GREEN M F.Prestressed FRP sheets for post-strengthening reinforced concrete beams[J].Journal of Composites for Construction,2001(5):214-220.
[7]	EL-HACHA R,WIGHT R G,GREEN M F.Prestressed carbon fiber reinforced polymer sheets for strengthening concrete beams at room and low temperatures[J].Journal of Composites for Construction,2004,8(1):3-13.
[8]	张轲,叶列平,岳清瑞. 预应力碳纤维布加固混凝土梁截面应力及抗弯刚度[J].建筑结构,2006,36(12):65-69.
[9]	邹经,杨勇新,陈伟,等. 预应力碳纤维板加固混凝土梁多次张拉时预应力损失分析[J].施工技术,2018,47(4):128-131.
[10]	王珍珍,周智,王佳钰.预应力碳纤维复材板加固桥梁短期预应力损失监测[J].工业建筑,2019,49(4):180-186.
[11]	中华人民共和国住房和城乡建设部.结构加固修复用碳纤维片材:JG/T 167-2016[S].北京:中国标准出版社,2016.
