FINITE ELEMENT ANALYSIS OF BUFFER-LAYER IN A NUCLEAR SAFETY RELATED STRUCTURE
-
摘要: 某核安全相关厂房结构设计中需考虑重型容器跌落产生巨大冲击作用的影响,在跌落位置铺设减振材料(如蒸压加气混凝土)形成减振层可有效减少跌落产生的冲击作用。以减振材料试验和结构缩尺试验为基础,采用ANSYS/LS-DYNA进行厂房减振层冲击荷载下的非线性动力有限元分析研究,确定了适用于蒸压加气混凝土的本构模型及其参数,探究了影响有限元分析结果的关键因素,并分析明确了抗压强度考虑堆砌影响的折减系数,有限元分析结果与试验结果具有良好的一致性。最终根据确定的本构、参数和方法,建立整体厂房的有限元模型进行冲击计算分析,确定减振设计和减振效果。
-
关键词:
- 减振层 /
- 蒸压加气混凝土 /
- ANSYS/LS-DYNA /
- 冲击 /
- 非线性
Abstract: In the structural design of a nuclear safety related plant, it is necessary to consider the impact of heavy container falling. Laying vibration reduction materials (such as autoclaved aerated concrete) at the falling position to form a buffer-layer can effectively reduce the impact caused by falling. Based on the vibration reduction material test and structural scale test, the nonlinear dynamic finite element analysis of the buffer-layer of the plant under impact load was carried out by using ANSYS/LS-DYNA, the constitutive model and its parameters suitable for autoclaved aerated concrete were determined, the key factors affecting the finite element analysis results were explored, and the reduction coefficient considering the influence of stacking was analyzed and defined. The finite element analysis results were in good agreement with the experimental results. Finally, according to the determined constitutive model, parameters and methods, the finite element model of the whole plant was established for impact calculation and analysis, and the vibration reduction design and vibration reduction effect were determined.-
Key words:
- buffer-layer /
- autoclaved aerated concrete /
- ANSYS/LS-DYNA /
- impact /
- nonlinear
-
[1] 高轩能, 刘颖, 王书鹏.基于LS-DYNA的大空间柱壳结构爆炸波压力场分析[J].振动与冲击, 2011(9):70-75. [2] 朱秀云, 林皋, 潘蓉, 等.基于荷载时程分析法的钢板混凝土结构墙的抗冲击性能敏感性分析[J].爆炸与冲击, 2016(5):670-679. [3] 孔庆勋, 李晓昆, 徐福泉, 等.乏燃料接收与贮存设施减振材料动力性能试验研究[J].施工技术, 2020(10):63-67. [4] 中华人民共和国住房和城乡建设部.蒸压加气混凝土建筑应用技术规程:JGJ/T 17-2008[S].北京:中国建筑工业出版社, 2008. [5] LI Z, FANG Q.Study of Autoclaved Aerated Concrete Masonry Walls Under Vented Gas Explosions[J].Engineering Structures, 2017(141):444-460. [6] 中华人民共和国住房和城乡建设部.混凝土结构设计规范:GB 50010-2010[S].北京:中国建筑工业出版社, 2015.
