预应力混凝土内部锚固区拉压杆模型的修正

赵建立; 沈水龙

doi:10.13204/j.gyjz200912015

预应力混凝土内部锚固区拉压杆模型的修正

doi: 10.13204/j.gyjz200912015

1.
上海交通大学土木工程系,上海 200240

基金项目:

上海市重点学科建设项目(B208)资助

详细信息

作者简介:
赵建立，男，1979年8月出生，博士研究生。E-mail:zhaojianli@sjtu.edu.cn

计量
- 文章访问数: 94
- HTML全文浏览量: 5
- PDF下载量: 58
- 被引次数: 0
出版历程
- 收稿日期: 2009-01-15
- 刊出日期: 2009-12-20

MODIFICATION OF FIP STRUT-AND-TIE MODEL FOR DESIGN OF INTERIOR ANCHORAGE ZONES OF POST-TENSIONED CONCRETE STRUCTURES

1.
Department of Civil Engineering,Shanghai Jiaotong University,Shanghai 200240,China

摘要

摘要: 针对国际预应力协会(FIP)给出的预应力混凝土内部锚固区拉压杆模型的缺陷和不足,基于有限元分析和拉压杆模型基本理论,提出一种修正FIP模型的方法,适用于各种构件尺寸比(b/h)的情况。通过有限元分析,得出构件的内力比F/P与尺寸比b/h曲线。并对FIP模型的应用局限性和模型修正的方法进行讨论。与FIP模型相比,修正后模型中拉杆的内力大小和相对锚具的位置均做出调整,并且按修正后的模型设计配筋,可节约近30%的内部锚固区普通钢筋用量。
- 后张法预应力混凝土 /
- 内部锚固区 /
- 拉压杆模型 /
- 有限元方法
Abstract: A stress analysis of the interior anchorage zones of post-tensioned concrete structures(IAZPTCS) is conducted using FEM.According to the analytical results,it is found that there are some limitations of the present design method(strut-and-tie model,STM) for IAZPTCS as recommended by International Federation for Prestressing(FIP) in 1996.A modified approach of STM is proposed.Comparing with the original FIP model,in the proposed approach,the locations and the internal forces of the ties and struts are adjusted,and the dimensional ratio of the width of the anchorage over the width of the member(b/h) can be varied in a wide range.By using the proposed model,the amount of reinforcement can be decreased by about 30% in the interior anchorage zones.
- post-tensioned concrete /
- interior anchorage zone /
- strut-and-tie model /
- finite element method

HTML全文

参考文献(10)

[2] FIP Recommendations 1996.Practical Design of Structure Concrete[S].International Federation for Prestressing(FIP),1996.

GB 500102002混凝土结构设计规范[S].

[3] Schlaich J,Schafer K,Jennewein M.Toward a Consistent Design ofReinforced and Prestressed Concrete Structures[J].PCI Journal,1987,32(3):74-151.

[4] Marsch E.Ueber die Berechnung der Gelenkquader[M].Beton-und-Eisen,1924(12):156-161.

[5] Burdet O L.Analysis and Design of Anchorage Zones in Post-TensionedConcrete Bridges[D]Austiun:University of Texas at Austin.1990.

[6] Sanders D H.Design and Behavior of Post-Tensioned ConcreteAnchorage Zones[D].Texas:University of Texas at Austin.1990.

[7] AASHTO.AASHTO LRFD Bridge Design Specifications[S].4thEdition.American Association of State Highway Officials(AASHTO).2006.

[8] Leu L J,Huang C W.Strut-and-Tie Design Methodology for Three-Dimensional Reinforced Concrete Structures[J].Journal of StructuralEngineering,2006,132(6):929-938.

[9] Bakir P G,Boduroglu H M.Mechanical Behavior and Non-LinearAnalysis of Short Beams Using Softened Truss and Direct StrutTieModels[J].Engineering Structures,2005,27(4):639-651.

[10] Kwak H G,Noh S H.Determination of Strut-and-Tie Models UsingEvolutionary Structural Optimization[J].Engineering Structures,2006,28(10):1440-1449.
